EX-1594HMS-PL
3. Layout, Connections & Jumpers
3.1 Layout
7-24V T-Block for optional
external Power Supply
3.2 Connections
+7V - 24V T-Block:
GND (Ground)
+7V - 24V
USB 2.0 A-Port:
© Copyright 2024 by EXSYS Vertriebs GmbH. All Rights Reserved
Upstream B-Port
Power LED
ATTENTION!
Please pay attention to the correct polarity!
Never connect power to GND it will destroy your
Hardware!
Never connect the power supply to the terminal block
while it is switched on!
USB 2.0 A-Port
Pin
1
2
1x USB 2.0
4x USB 2.0
Downstream A-Port
Signal
Pin
VCC
3
DATA-
4
11
English
Reset Button
Status LED for
each Port
Signal
DATA+
GND
