6. Commissioning, operation
Measuring assemblies
Proven measuring assemblies for various types of media. The assemblies that are
particularly recommended for use are shown below.
Liquid media
Filling of the liquid
measuring
line
Examples
conden-
sate
Pressure
gauge above
the tapping
point
Pressure
gauge below
the tapping
point
Dimensions in mm
DELTA-plus model DPG40
WIKA operating instructions DELTA-plus, DELTA-comb and DELTA-switch
liquid complete-
with ly vapour-
vapour ised
boiling "liquid gases" dry air
liquids
Gaseous media
gaseous partially
condensed
(damp)
moist air
flue gases
EN
complete-
ly con-
densed
steam
