device. The operator or user of the
machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
The device is part of the
X 20 V TEAM series and can be
operated with batteries of the
X 20 V TEAM series. Batteries of
the X 20 V TEAM series may only
be charged using chargers of the
X 20 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Cordless Impact Driver
• 2 Bits (PZ1 + PZ2, length: 50 mm)
• 1 Auxiliary handle
• 1 Storage case
• Original instructions
The rechargeable battery and char-
ger are not included in delivery.
Overview
The illustrations for the
device can be found on
the front fold-out page.
1 Drill chuck aperture
2 Keyless chuck
3 Torque adjustment ring
4 Gear selector switch
5 Magnet
6 Direction of rotation switch
7 Handle
8 Battery holder
9 LED work light
10 On/Off switch
11 Holder for auxiliary handle
12 Bits
13 Auxiliary handle (Insulated grip-
ping surface)
14 Charger
15 Battery
16 Button (Charge level indicator)
17 Charge level indicator
18 Battery release
19 Storage case
Fig. D
20 Belt clip
Description of functions
The 3-in-1 cordless impact drill
screwdriver with two-speed gear-
box has 20 torque settings, as well
as one drill setting and one impact
setting, right/left rotation. The tool is
equipped with a keyless chuck and
an LED work light.
Please refer to the descriptions below
for information on how the operating
elements work.
Technical data
Cordless Impact Driver
................................. PSBSA 20-Li C3
Rated voltage U ...................... 20 V ⎓
No-load rotation speed n
– Level 1 ......................... 0–440 min
– Level 2 ....................... 0–1650 min
Max. torque ..............................45 Nm
Impact rate .................. 0-26400 min
Chuck capacity ................. 1,5-13 mm
Weight with battery (20 V, 2 Ah)
.................................................≈1.9 kg
GB
IE
NI
0
−1
−1
−1
5
