28. Before using a machine again, check carefully to ensure
that it is in proper working order for the task you have in
mind for it.
29. Examine the alignment and attachment of mobile parts,
look for any broken parts, and inspect the assembly and
other conditions that could affect operation.
30. Any damaged element, whether
should be repaired or replaced by an authorised
technical service outlet, unless otherwise specified in this
instruction manual.
Have defective switches replaced by an authorized
31.
service technician.
32. Do not use the machine
off.
33. Do not mix material with inflammation points lower than
210C.
34. Do not use solvents
dangerous due to risk of explosion.
35. The use of any accessory or complement other than
those recommended in this instruction manual may be
hazardous.
36. Have the machine repaired by qualified personnel. This
electric tool complies
requirements. Repairs should only be made
qualified staff using
Otherwise, the user risks considerable injury.
C. KNOW YOUR PRODUCT
RUBIMlX-9 BL
Machine components.
Handle.
2 Onloff switch.
3 Electronic speed regulator.
4 Mechanical speed regulator (I / II)
5 Switch retention-off button.
6 Motor protection casing
Ventilation grille.
7
8 Tool holder.
9 Auxiliary spanner (19 mm).
10 Spanner (22 mm).
II Mixing tool max. Ø 120 mm
RUBIMlX.9 BL DUPLEX
Machine components.
Handle.
2 On/off switch.
3 Electronic speed regulator.
4 Switch retention-off button.
5 Motor protection casing
Ventilation grille.
6
7 Tool holder.
8 Auxiliary spanner (22 mm).
9 Spanner (28 mm).
10 Mixing tool Ø 220 mm. (2 x 120 mm)
D. STARTING THE MACHINE
Items to be checked before starting the machine
Before using this machine, verify that no parts are worn out,
damaged or broken. Should you find any part that is not in
proper condition, have it repaired or replaced immediately.
The input voltage must be the sameasthe vo tage indicated on
ENGLISH
protective or not,
if it cannot be switched on and
to clean the tools. It could
with the pertinent safety
original replacement parts.
the machine features
connected to 2 IOV
loov
Incorrect use may damagethe tool.
Follow the instructions
Only use mixing tools up to the maximum indicated
diameter.
When using the mixing tool, make sure the revolutions do
not drop sharply Or the machine stops.
Switching on and Off
Switching on
- First press the switch retention off button and then press the
on switch.
Switching Off
be
Release the on switch
RUBIMlX-9 BL
Mechanical speed regulator
With the machine turned off, turn the switch to change the
speed.
When the speed cannot be changed by turning the switch
completely, turn the mixer paddles slightly and then change
the speed.
RUBIMlX-9 BL 1 RUBIMlX-9
Electronic speed regulator
- Press the on switch and turn the regulating switch on the
right to obtain the desired speed.
The number of revolutions
material and can be determined by testing.
After working at a low number of revolutions, leave the
machine to operate without load at maximum revolutions
for about 3 minutes
E. INSTRUCTIONS
RUBIMlX-9 BL 1 RUBIMlX-9
Before any adjusting or fine tuning.
-Turn the machine
-Take out the plug.
-Wait until the machine has completely stopped.
Mixer.
Inserting the mixer.
RUBIMlX.9 BL
Take out the two parts that make up the mixer paddle from
the box.
Screw the two parts together. Use the 22 mm spanner to
screw in the two parts correctly.
Screw the top part of the mixer paddle into the mixer output
axis M 14.
Using the 22 mm spanner screw in the mixer paddle tightly,
turning it to the right. Use the 19 mm auxiliary spanner in the
output axis to secure the mixer paddle.
RUBIMlX-9 BL DUPLEX
Insert the mixer paddle into the corresponding output axis
lining up the top groove of the paddle with the output axis
accessory.
- Move the caseforwards and screw it into the mixer paddle.
using the 28 mm spanner screw the case in tightly turning to
the right. Use the 22 mm auxiliary spanner in the output axis
to secure the mixer paddle.
