QMC41-100-I06
Technical Data
Normal environmental conditions
This product is designed to be safe under the following con-
ditions:
• Indoor use
• Altitude up to 2 000 m
• Operating temperature +5 °C / +41 °F to +40 °C / +104
°F
• Maximum relative humidity 80 % for temperatures up to
31 °C / 89 °F decreasing linearly to 50 % relative humid-
ity at 40 °C / 104 °F
• Mains supply voltage fluctuations up to ±10 % of the
nominal voltage
• Transient overvoltages up to the levels of overvoltage
category ll
• Temporary overvoltages occurring on the mains supply
• Pollution degree 2
• Ingress protection rating:
Product data
Motor voltage
Motor power
Speed
Torque range
Weight
Declarations
Liability
Many events in the operating environment may affect the
tightening process and shall require a validation of results. In
compliance with applicable standards and/or regulations, we
hereby require you to check the installed torque and rota-
tional direction after any event that can influence the tighten-
ing result. Examples of such events include but are not lim-
ited to:
• initial installation of the tooling system
• change of part batch, bolt, screw batch, tool, software,
configuration or environment
• change of air- or electrical connections
• change in line ergonomics, process, quality procedures
or practices
• changing of operator
• any other change that influences the result of the tighten-
ing process
The check should:
• Ensure that the joint conditions have not changed due to
events of influence.
• Be done after initial installation, maintenance or repair
of the equipment.
24 V d.c.
145 W
2000 r/min
25 - 100 Nm (2.2 - 8.9 in lb)
0.61 kg (1.36 lb)
© Atlas Copco Industrial Technique AB - 9834 3502 00
• Occur at least once per shift or at another suitable fre-
quency.
EU DECLARATION OF INCORPORATION
AND EU DECLARATION OF CONFORMITY
We Atlas Copco Industrial Technique AB, S-105 23
STOCKHOLM SWEDEN, declare under our sole responsi-
bility that this product (with name, type and serial number,
see front page) fulfills the following essential requirements
of Machinery Directive 2006/42/EC, and must not be put
into service until the final machinery, into which it is to be
incorporated, has been declared in conformity with that Di-
rective. It is in conformity with the following Directive(s):
2006/42/EU, 2011/65/EU, 2014/30/EU
Harmonized standards applied:
EN 61000-3-2:2014, EN 61000-3-3:2013, EN
61000-6-2:2005 + AC:2005, EN 61000-6-3:2007 +A1:2011,
EN 61010-1:2010, EN 61326-1:2013
The relevant technical documentation was compiled and was
communicated in accordance with Machinery Directive
2006/42/EC part B of Annex VII. Authorities can request the
relevant technical information from:
Product Compliance Manager, Atlas Copco Industrial Tech-
nique AB, S-105 23 Stockholm Sweden
Stockholm, 11 June 2018
Carl von Schantz, Managing Director
Signature of issuer
Noise and Vibration Declaration Statement
• Sound pressure level <70 dBA dB(A) , uncertainty 3
dB(A), in accordance with ISO15744.
• Sound power level <80 dB(A) , uncertainty 3 dB(A), in
accordance with ISO15744.
• Vibration total value <2.5 m/s
dance with ISO 20643.
These declared values were obtained by laboratory type test-
ing in accordance with the stated standards and are suitable
for comparison with the declared values of other tools tested
in accordance with the same standards. These declared val-
ues are not adequate for use in risk assessments and values
measured in individual work places may be higher. The ac-
tual exposure values and risk of harm experienced by an indi-
vidual user are unique and depend upon the way the user
works, the workpiece and the workstation design, as well
upon the exposure time and the physical condition of the
user.
Safety Information
2
, uncertainty -, in accor-
3
