Tab. 8 :
Control outputs of the UII
control module
Installation
All manuals and user guides at all-guides.com
Status query via the UII control module
The UII control module (Universal Interconnectivity Interface) offers several control outputs (Tab. 8). They
are designed as potential-free relay switch-over contacts The control outputs are designed for transmis-
sion of status messages about the motorised multi-point lock 519, the door status and the UII control
module. They can be used to control external devices.
Status output/
Description
control output
Fault / alarm
Alarm signal:
· The lock could not lock properly.
· The striking plate was not recognised.
· BMA input alarm message or jumper open.
· External door contact not recognised or jumper open.
· Door remains open for too long in escape door con-
The alarm is switched off again by pressing the release
button (Tab. 3, Unlocking control input).
Swing door drive
Actuation of the swing door drive; With complete un-
locking of the lock, the output is switched, as a release
signal for a swing door drive ("Configuration of the UII
control module / meaning of the switches", page 64).
Door handle / profile
Status message about the pressed door handle or the
cylinder
actuated profile cylinder. The query depends on the
configuration of the DIP switch ("Configuration of the UII
control module / meaning of the switches", page 64).
Door status
OPEN/CLOSED door status message queried by the
internal striking plate sensor. if an external contact is
connected, it is also queried in the OPEN/CLOSED door
status message ("Control via the UII control module",
page 63).
Locking
Status message as to whether the lock is locked or
unlocked.
Fire alarm
Alarm signal: A control signal on the fire alarm system
or the triggering of a smoke detector line ("Control via
the UII control module", page 63) has been received.
The fire protection module ("Electrical accessories",
page 79) can be connected to this output, which
then controls locking of the motorised multi-point lock
519 ("Control via the UII control module", page 63).
trol unit mode
(Tab. 7, DIP switch).
Description
· nc = normally closed
· no = normally open
· Alarm (nc)
· No alarm (no)
· Drive off (nc)
· Drive on (no)
· Not actuated (nc)
· Actuated (no)
· Open (nc)
· Closed (no)
· Unlocked (nc)
· Locked (no)
· Alarm (nc)
· No alarm (no)
EN
67
