The charger is not connected to the battery.
1. Connect the charger to a suitable wall socket.
à The power indicator is on.
2. Press and hold the button MODE to enter power supply mode. The POWER SUPPLY in-
dicator will light up.
3. Press and hold the button MODE to return to standby mode. The STANDBY indicator will
light up.
7.5 Disconnecting the charger from the battery
1. Disconnect the charger from the power supply.
2. Disconnect the black (-) clamp from the negative (-) battery terminal.
3. Disconnect the red (+) clamp from the positive (+) battery terminal.

8 Cleaning and care

Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They damage the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the charger from the power supply.
2. Disconnect the charger from the battery.
3. Let the product cool down to ambient temperature.
4. Clean the product with a dry, fibre-free cloth.
9 Disposal
This symbol must appear on any electrical and electronic equipment placed on
the EU market. This symbol indicates that this device should not be disposed of
as unsorted municipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose
of it separately from unsorted municipal waste. Spent batteries and accumulators,
which are not enclosed by the WEEE, as well as lamps that can be removed from
the WEEE in a non-destructive manner, must be removed by end users from the
WEEE in a non-destructive manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-
back of waste. Conrad provides the following return options free of charge (more details on
our website):
■
in our Conrad offices
■
at the Conrad collection points
■
at the collection points of public waste management authorities or the collection points
set up by manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply
in countries outside of Germany.

10 Technical data

10.1 Charger
Input ............................................... 220 – 240 V/AC, 50 Hz
Output............................................. Normal cold/AGM:
Supported battery types ................. 6V/12 V Lead-acid batteries (Wet, Gel, MF, and AGM)
Supported battery capacity............. 6V/12V Lead-acid batteries: 1.2 - 120 Ah
Charging activating voltage ............ Lead-acid batteries 6 V: >3.7V
Trickle charging current.................. < 200 mA
Fuse................................................ T2A (non-replaceable)
Protection class .............................. II
Ingress protection........................... IP65
Protection ....................................... Overcharge, reverse polarity, overheating, short circuit
Dimensions (W x H x D) ................. 194.6 x 41.5 x 81.2 mm
Weight ............................................ 550 g
6
6 V/DC 6 A
12 V/DC 6 A / 0.9 A
Power supply: 13.6 V/DC 6 A
LiFePO4: 12.8 V/DC, max. 6 A
Recovery: 12 V
12.8 V LiFePO4 (with battery management)
Not suitable for emergency or starter batteries of
electric vehicles (EVs)
LiFePO4 batteries (12.8 V): 8 - 50 Ah
Lead-acid batteries 12 V: >7.0 V
LiFePO4 batteries: >11.6 V s
10.2 Environment
Operating conditions....................... 0 to +40 °C
Storage conditions.......................... -30 to +60 °C
10.3 Other
Input cable length ........................... 1.85 m
Output cable length ........................ 1.5 m
Cable with alligator clips................. 0.4 m
