Huawei SUN2000-M2 Kurzanleitung Seite 6

No. Item
1 PE cable
2 AC output power cable
3 DC input power cable
4 (Optional) RS485
communications cable
5 (Optional) RS485
power meter signal
cable
6 (Optional) Rapid
shutdown switch signal
cable
7 (Optional) Grid
scheduling signal cable
8 AC switch
Type Specifications
Single-core Conductor cross-sectional area:
outdoor copper •
cable
•
Outdoor copper Conductor cross-sectional area:
cable •
•
Cable outer diameter: 11–26 mm
Standard outdoor •
PV cable in the •
industry
Two-core outdoor •
shielded twisted
pair cable •
Five-core outdoor
cable
Rated voltage ≥ 415 V AC
Recommended:
Rated current:
three-phase AC
circuit breaker •
•
5
2
≥ 6 mm (SUN2000-8KTL-M2/SUN2000-
10KTL-M2/SUN2000-12KTL-M2)
2
≥ 10 mm (SUN2000-15KTL-M2/SUN2000-
17KTL-M2/SUN2000-20KTL-M2)
2
6–16 mm (SUN2000-8KTL-M2/SUN2000-
10KTL-M2/SUN2000-12KTL-M2)
2
10–16 mm (SUN2000-15KTL-M2/SUN2000-
17KTL-M2/SUN2000-20KTL-M2)
Conductor cross-sectional area: 4–6 mm
Cable outer diameter: 5.5–9 mm
Conductor cross-sectional area: 0.2–1 mm
2
(0.5 mm is recommended)
Cable outer diameter: 4–11 mm
25 A (SUN2000-8KTL-M2, SUN2000-10KTL-
M2, SUN2000-12KTL-M2)
40 A (SUN2000-15KTL-M2, SUN2000-
17KTL-M2, SUN2000-20KTL-M2)
2
2
