Inbetriebnahme
Private Sub DecodeFrame(Rec As String)
Dim idx As Integer
Dim Value As Long
Dim PlsString As String
Dim SingleValue As String
Dim p As Integer
' Alle Zeichen aufsammeln
ReceiveBuffer = ReceiveBuffer + Rec
' Schon 1 Wert empfangen
p = InStr(ReceiveBuffer, Chr$(13))
If p > 0 Then
' -> Einzelnen Wert ausschneiden
SingleValue = Left$(ReceiveBuffer, p -
1)
ReceiveBuffer = Mid$(ReceiveBuffer, p +
1)
Else
SingleValue = ""
End If
If Len(SingleValue) > 9 Then
' Frame pruefen
' =001#FAULTCR
' =001#- 100.1CR
If Left(SingleValue, 1) = "=" Then
If Mid$(SingleValue, 5, 1) = "#"Then
idx = Val(Mid$(SingleValue, 2,3))
If Mid$(SingleValue, 9, 1) > "9"
Then
Status(idx) = False
Else
Status(idx) = True
' Zahlenwert ausschneiden
PlsString = Mid$(SingleValue,
6)
' Vorzeichen oder ' '
beachten
If Mid$(PlsString, 1, 1) =
" " Then
PlsString =
Mid$(PlsString, 2)
End If
' Wenn '.' im Telegramm ->
entfernen
p = InStr(PlsString, ".")
If p > 0 Then
PlsString =
Left$(PlsString, p - 1) +
Mid$(PlsString, p + 1)
End If
' Ende erkennen
VEGACOM 557 VEGA ASCII
p = InStr(PlsString, "%")
If p > 0 Then
PlsString =
Left$(PlsString, p - 1)
End If
' Text in Zahl wandeln
PLS(idx) = CLng(PlsString)
End If
' Ende erreicht ?
If idx = (StartIndex + LenIndex)
- 1 Then
' Fehlerzaehler = 0
InAction = 0
' Werte Anzeigen
DisplayValues
End If
End If
End If
End If
End Sub
Public Sub DisplayValues()
Dim i As Integer
Dim Disp As String
' Anzeige loeschen
List1.Clear
' Schleife ueber alle Werte
For i = StartIndex To (StartIndex +
LenIndex) - 1
' Anzeige Text aufbereiten
Disp = "PLS " + Format$(i, "000")
+ " = "
If Status(i) Then
Disp = Disp + Format$(PLS(i),
"000000000")
Else
Disp = Disp + "---"
End If
' Anzeigen
List1.AddItem Disp
Next i
End Sub
Public Sub ClearValues()
Dim i As Integer
' Alle Statusinformation loeschen
For i = StartIndex To (StartIndex +
LenIndex) - 1
Status(i) = False
Next i
End Sub
