8.2
Teileliste
Nr.
Bezeichnung (ENG)
1
Backrest
2
Backrest Frame
3
Adjustable Boom
4
Foot Bar
5
Rear Rod
6
Handlebar
7
Steel Heel Holder Bracket
8
Rear Frame
9
Front Frame
10
Pivot Arm
11
Ratchet Handle
12
Handlebar Foam Grip
13
Front Rod
14
Rubber Heel Holder
15
Angle Control Bar
16
Foam Grip
17
Plastic Spacer
18
Plastic Round End Cap
19
Flat Washer Φ16xΦ8.5x1.5
20
Curved Washer Φ16xΦ8.5x1.5
21
Hex Bolt M8x23mm
22
Rod Cap
23
Hex Bolt M8x40mm
24
Square End Cap
25
Square End Cap 38
26
Safety Pin Φ8x63.5mm
27
Rubber Pad
28
Hex Socket Head Bolt M8x20mm
29
Plastic Washer
30
Foot Bar Oval End Cap
31
Foot Cap
32
Hex Bolt M8x58mm
Anz.
Nr.
Bezeichnung (ENG)
1
33
Lumbar Pad
1
34
Handlebar Cap
1
35
Rod
1
36
Spring
1
37
Lower Bed Frame Bushing
2
38
Knob
4
39
Flat Washer Φ30xΦ10.5x0.5
1
40
Flat Washer Φ25xΦ10.5x2.0
1
41
Spring Knob
2
42
Nylon Nut M8
1
43
Flat Washer Φ16xΦ8.5x2.0
2
44
Metal Bushing
1
45
Hex Bolt M8x53mm
4
46L
Left Plastic Cover
1
46R
Right Plastic Cover
1
Hex Socket Head Cap Bolt
47
M10x30mm
4
2
48
Nylon Nut M10
21
49
Screw M5
2
50
Nylon Nut M5
4
51
Screw M8
4
52
Han lebar Round End Cap Φ25
6
53
Latch
6
Self-Tapping Phillips Screw
54
ST3.5*13
3
1
Self-Tapping Phillips Screw
55
ST4.0*16
2
2
56
Socket Phillips Screw M5x18mm
4
57
Button
2
61
Hex Bolt M8x50mm
4
62
Hex Bolt M8x60mm
2
Anz.
1
1
1
1
4
1
2
3
1
14
1
1
1
1
1
1
1
1
1
1
2
1
3
2
1
1
2
6
33
