8.2 Teileliste
Nr. Bezeichnung (ENG)
1 Main frame
2 Left handlebar post
3 Right handlebar post
4 Handlebar set
5 Front handlebar set
6 Stabilizer
7 Computer supporting tube
8L Lower cover for handlebar
post(left)
8R Lower cover for handlebar
post(right)
9 Flat washer
10 Allen bolt
11 Cross bolt
12 CSK inner hexagon bolt
13 Wooden board
14 Buff er bar
15 Metal clip
16 Flat washer
17 Running belt
18 Allen bolt
19 Pedaling plate welding set
20a Pedaling plate
20b Decorative strip for pedaling
plate
21 Pedal cover
22 Buff er pedal pad
23 Cross screw
25 Buff er 4
26 Buff er 3(black)
27 Flat washer
28 Anti-loose nut
29 Allen bolt
38
Hrst. Teilenummer
264C1-3-1000-B99
264C1-3-1300-B92
264C1-3-1400-B92
264C1-3-1500-B93
264A1-3-1550-B90
264C1-3-1600-B92
264A1-3-2000-B91
264C1-6-1371-B0
264C1-6-1471-B0
55105-1-1510-DA
54010-8-0065-CU7
52605-2-0015-F0
51608-5-0035-F0
264C1-6-1073-B0
264C1-6-1084-B0
264C1-6-1086-J1
55104-1-1210-NA
264C3-6-1072-B0
50308-5-0035-F0
264C1-3-1055-B90
264C1-6-1076-B4
264C1-6-1092-B0
264C1-6-2424-B0
264C1-6-1061-B1
52842-2-0015-F0
26100-6-1088-F0
26100-6-1083-B0
55108-1-1612-FA
55208-1-2008-FA
50308-5-0020-UF0
Spezifi kation
452.5*296.2*75.7
452.5*296.2*75.7
D15*D5.2*1.0T
M10*1.5*65L,12.94
M5*0.8*15L
M8*1.25*35L,8.8
1445*695*25T
25*2T*1380L
30*40*6
D12*D4.3*1.0T
600*4.3T*3500L
M8*1.25*35L,8.8
150*195.5*1385L
570.3*165.3*59
1197*100.7*2.7T
ST4.2*15L
D30*37L*M8
D30*37L*M8,95
D16*D8.5*1.2T
M8*1.25*8T
M8*1.25*20L,8.8
T10.5 Pro
Anz.
1
1
1
1
1
1
1
1
1
4
6
27
8
1
2
16
4
1
2
1
2
2
1
2
69
2
2
10
6
2
