5. Take the end of the nail belt and lead it counterclockwise under the brake through into the nail shaft guide.
6. Pull the nail belt through the nail shaft guide until it reaches the pusher.
7. Close the door until the lock engages.
8. Insert the nail tip guide again. Lift the spring bar slightly and slide the nail tip guide until it clicks into place near the
nail tips.
9. Slide the cover plate on the mandrel and secure the cover plate by tightening the clamping lever.
7 Troubleshooting
Risk
Unplug the unit always from the air supply before execution of the work described below.
7.1 Jamming in guidebody
Remove deadlocks on head through the following steps
•
Unplug the unit for the air supply
•
Open the door of the nail guide by pressing the shutter.
•
Remove the jammed fastener with a suitable tool
•
Pull the nail belt trough until the pusher
•
Close the door until the lock engages.
Attention
If a failure or malfunction cannot be resolved , please give the equipment to a qualified
person who can carry out the repair.
8 Maintenance
8.1 Maintenance intervals
Comply with the listed maintenance intervals to ensure continuous faultless operation.
Disconnect the compressed air supply during every maintenance.
8.2 Weekly
Weekly
•Check the tool for leaks, damages, completeness of all parts and tightness of all screws.
8.2 Monthly
Monthly
•Clean the tool with compressed air.
•Lightly grease the movable parts.
9 Repairs
Repairs may only be carried out by personnel authorized by the manufacturer or other
competent professionals using original Senco spare parts.
10 Warranty
The device was developed and manufactured in accordance with the latest technical knowledge. We provide the initial
purchaser with a warranty according to statutory requirements for function, materials, and processing. Normal wear and
tear is excluded.
The warranty ends if improper treatment, use of force, repairs by third parties, or the installation of non-original
replacement parts is evident.
The warranty covers repair or replacement at our discretion. A warranty extending beyond the scope of delivery is
precluded, since proper and expert use of the device is outside our control.
Please note our terms of business!
11 Disposal
Take the device, packaging, and accessories to an environmentally friendly recycling centre (in accordance
with European Parliament and Council Directive 2002/96/EC of January 27, 2003).
