English
Setting-up operation
A maximum of 10 transmitters per channel can be taught in parallel.
Therefore the LEDs indicate the operation modes. After providing the
operating voltage to the receiver the orange LED 1 flashes when no
switch has been taught in. If the orange LED 1 is off, switches have
already been taught in.
Selection of operation mode
There are six different operation modes that can be selected after
switch-on. For selection keep push-button S1 pressed while switch-
ing on the receiver. The desired operating mode is confirmed by quick
pressing of the push-button S1 again, (approx. 1 s). If you do not press
the push-button S1 again the next operation mode is switched on after
5 s. The operation modes »Conjunction« and »Latching function« can
be selected in addition to the other operation modes.
Operation LED 1 LED MD
mode
Standard flashes flashes
fast fast
Standard flashes on
inverse output fast
Relay ener-
on flashes
gised
fast
Relay ener-
on on
gised, inverse
output
Conjunction
flashes on
(additionally
slowly
selectable)
Latching
on flashes
function
slowly
(additionally
selectable)
Teaching in of switches
- press push-button S1 approx. 1 s
- LED MD flashes slowly (2 Hz)
- press push-button S2 for channel seletion
- actuate switch/command device to be taught in
- the LED of the corresponding channel flashes short
- to leave teach-in mode press push-button S1 for approx. 1 s
- LED MD is on
Function
Relay energised by actuation
Relay de-energised by actua-
tion, inverse output signal
Relay energised by providing
operating voltage, de-energi-
ses after actuation
Relay energised by providing
operating voltage, de-ener-
gises after actuation, inverse
output signal
Relay energised, as soon as
one switch is actuated, de-
energises, when all taught-in
switches are not actuated
Latching function/impulse
function
Deleting one switch
- press push-button S1 for 5 s until LED MD flashes fast
- press push-button S2 for channel seletion
- actuate switch/command device to be deleted
- the LED of the corresponding channel is off for short time
- press push-button S1 for approx. 1 s to leave delete mode
- LED MD lights green
Inverse teaching in of one switch
- procedure like teach-in but switch must be actuated before
procedure is started by pressing S1
Deleting all switches
- press push-button S1 for 5 s
- LED MD flashes fast (5 Hz)
- LED channel selection is on
- release push-button S1
- repress push-button S1 for 5 s until LED MD is off
- LED MD is on and LED 1 is off
- Operation mode is set back to standard
- release push-button S1
- LED MD is on and LED 1 flashes fast
RF Rx SW868/915-2W-RS232
Selection of the baud rate
- standard preset baud rate is 9 600 Bd
- press push-button S1 and S2
- LEDs 1, 2 and MD flash
- press push-button S1 for selection of baud rate
- LEDs B1 and B2 indicate the baud rate
- press push-button S1 to select the desired baud rate
LED B1 LED B2 Baud rate
off off 9 600 Bd
on off 19 200 Bd
off on 38 400 Bd
on on 57 600 Bd
- press push-button S1 to show the selected baud rate
- press push-button S1 and S2 to quit without changing the setting
Telegrams
All steute Wireless telegrams are displayed at the serial interface.
