RF Rx SW868/915-2W / RF Rx SW868/915-2W-RS232
//
Montage- und Anschlussanleitung / Funkempfänger
Mounting and wiring instructions / Radio receiver
Instructions de montage et de câblage / Récepteur radio
Istruzioni per il montaggio e per il collegamento / Ricevitore radio
Instruções de montagem e instalação / Receptor de rádio freqüência
Инструкции Монтаж и Коммутация / Приемник радиосигнала
deutsch
Löschen eines Schalters
- Taster S1 für 5 s drücken bis LED MD schnell blinkt
- Taster S2 zur Kanalwahl drücken
- zu löschenden Schalter/Befehlsgerät betätigen
- die dem Klanal entsprechende LED erlischt kurz
- zum Verlassen des Lösch-Modus Taster S1 ca. 1 s betätigen
- die LED MD leuchtet grün
Invertiertes Einlernen eines Schalters
- Prozedur wie beim Einlernen aber Schalter muss betätigt sein, bevor
die Prozedur mit S1 eingeleitet wird
Löschen aller Schalter
- Taster S1 für 5 s drücken
- LED MD blinkt schnell (5 Hz)
- Kanalwahl LED leuchtet
- Taster S1 nicht mehr drücken
- Taster S1 für 5 s erneut drücken bis LED MD erlöscht
- LED MD leuchtet und LED 1 leuchtet nicht
- Betriebsart wird auf Standard zurückgesetzt
- Taster S1 nicht mehr drücken
- LED MD leuchtet und LED 1 blinkt schnell
RF Rx SW868/915-2W-RS232
Auswahl der Baudrate
- Standard-Baudrate ist 9 600 Bd
- Taster S1 und S2 drücken
- LEDs 1, 2 und MD blinken
- Taster S2 zur Auswahl der Baudrate drücken
- LEDs B1 und B2 zeigen die Baudrate an
- Taster S1 betätigen zur Auswahl der gewünschten Baudrate
LED B1 LED B2 Baudrate
aus aus 9 600 Bd
an aus 19 200 Bd
aus an 38 400 Bd
an an 57 600 Bd
- Durch Betäigen des Tasters S1 wird die ausgewählte Baudrate
angezeigt
- Durch Betäigen der Taster S1 und S2 verlassen ohne Änderung
der Einstellung
Telegramme
Alle steute Wireless Telegramme werden auf der seriellen Schnittstel-
le ausgegeben.
English
Destination and use
The two channel radio receiver is used to switch electrical loads via
radio transmission. The transmission is carried out at a frequency of
868.3 MHz or 915 MHz for USA and Canada. The transmitters must
conform to the steute Wireless protocol. The output of the receiver can
be switched by a maximum of 10 transmitters per channel. Therefore
each transmitter must be taught in once.
Mounting / Wiring
Only suitable antennas must be used. Antenna with 1.5 m cable and
SMA plug-in connector, Mat. No. 1188958 for the 868 MHZ receiver and
with 3.6 m cable and SMA reverse angled plug-in connector, Mat. No.
1188987 for the 915 MHz receiver. The antenna should be mounted on
a metal plate of 250 x 250 mm minimum size as an HF counterweight.
The sideways distance to the next adjacent wall or source of distur-
bance should be at least 300 mm. The antenna cable must not be bent
or clamped, minimum bending radius >15 mm.
Design of sensing range
Because radio signals are electromagnetic waves the signal is attenu-
ated on its way from the transmitter to the receiver. This means the
electrical as well as the magnetic field strengths decrease and in fact
inversely proportional to the squared distance of transmitter and re-
ceiver (E,H~1/r²). In addition to this natural restriction of the sensing
range further interference factors occur: Metal parts, e. g. armours in
walls, metal foils of thermal insulations or vapour deposited metal
layer heat protection glass reflect electromagnetic waves. Therefore a
socalled deadspot can be found behind them. Indeed radio waves are
able to penetrate walls but the attenuation increases even more than
in the free field. Penetration of radio waves:
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination
free field: Long Range LR approx. 450 m
Ultra Long Range ULR approx. 700 m
RF 96 approx. 400 m
Notices
The devices can be operated registration- and license-free on the
territory of the EC, Switzerland, Cyprus, Canada and the USA. The
use in other countries must be explicitely clarified! The electrical con-
nection may only be carried out by authorised personnel. The radio
receiver must not be used in connection with devices that may directly
or indirectly serve health- or life-saving purposes or cause hazards by
operation to human beings, animals or asset values. The declaration
of conformity is available on request or can be downloaded from our
website. Subject to technical modifications. The described products
have been developed in order to assume safety functions as part of an
entire plant or machine. The responsibility taken by the manufacturer
of a plant or machine implies a safeguarding of correct general func-
tion. Moreover steute does not assume any liability for recommenda-
tions made or implied by this description. From this description new
claims for guarantee, warranty or liability cannot be derived beyond
the general terms and conditions of delivery.
90...100%
65...95%
10...90%
0...10% sight connection in
