5
Operating instructions
5.1
Strapping
Preconditions
●
The charged battery is inserted (Section 4.1.2).
●
The desired operating mode is set (Section 4.2.).
In this description it is assumed that the selected operating mode (default mode) is "MAN"
●
Set the rotary knob (5) to position "strap insertion aid off"
●
Desired tension force is set (Section 4.3).
► Push the strap from the dispenser through
the seal (1), then guide it around the pack-
aged goods. See recommended steel straps
(Section 7).
► Push the strap start (2) underneath the al-
ready inserted strap through the seal again.
► Bend the strap start below the seal
(10–15 cm / 4"–6").
► Tighten the strapping by hand (pre-tesioning).
► Bend the strap coming from the dispenser
upwards behind the seal (3). This prevents the
strap from sliding back.
► Hold the tool with both hands.
► Pull the operating lever (4).
–
The rocker of the tensioning device opens.
► Insert the tool over the strap coming from the
dispenser as far as it will go.
► Push the tool forward up to the seal.
► Release the operating lever.
–
The strap is clamped in the tensioning
device.
If the rotary knob (5) is in the position
„strap insertion aid on"
sioning wheel remains up after pulling
the operating lever until the tensioning button (6)
is pressed. This means that the control lever does
not have to be held continuously.
WARNING
Strap tensioning or strapping, danger of jamming and crushing
Do not place hands or other body parts between the strap and the packaged goods
during the strapping process. Ensure that there are no other persons in the hazard zone
(Section 2.4).
For an emergency stop in the case of danger (trapped person): If no sealing has been
made yet, the strap tension can only be released by pulling the operating lever. Pressing
the tensioning or sealing button again only stops the tool. After sealing, cut the strap using
a suitable tool (strap cutter).
40 of 50
, the ten-
SIGNODE BPT-H32
1
3
2
4
5
V 11.21_EN
