AWG Z2 Originalbetriebsanleitung Seite 28

AWG | Fittings | Inductors Z2, Z4 and Z8
3 .4 Characteristic values
Flow rate at 5 bar
Max. operating pressure
Admixing rate
Operating temperature
3 .5 Overview
1 2
1
Screen (depending on the model)
2 Inlet side thread
3 Nozzle body
4
Suction device
5 Setting scale
Fig. 1 Overview AWG Inductors Z2, Z4 and Z8
M1061B10 | Rev. 03-08/24
3 4 5
Z2 Z4
200 l/min 400 l/min
16 bar (PN16)
1 / 2 / 3 / 4 / 5 / 6 %
- 20 °C** to + 60 °C
* with running wate
7
6
9
10
6
Arrow indicating flow direction
7 Tube
8 Outlet side thread
9
Tube base stand
10 Setting sleeve
dEScription
Z8
800 l/min
r
8
