6.10.4 - CT10324F ADVANCED MENU (ADV)
CT10324F
1
foto1 setup
2
foto2 setup
3
photo test
4
type edge
5
setup edge
6
test edge
7
flash setup
50
VECCHIA
CT10224F
Defines the behaviour of the automation, starting
from the closed position
0 = if PH1 is engaged, no opening command
SP.h.
is executed
1 = if PH1 is engaged, it still executes the opening
command
Checking the engaged status of PH2
0 = active during both the opening and the closing
Ph.2.
manoeuvres
1 = only active during the opening manoeuvre
Photocell functionality test
0 = no test
1 = checks the functionality of the photocells
connected to the PH1 terminal
tP.h.
2 = checks the functionality of the photocells
connected to the PH2 terminal
3 = checks the functionality of the photocells
connected to the PH1 and PH2 terminals
Defines the type of safety connected to the EDGE/
STOP terminals
0 = STOP NC contact
Ed.m.
1 = 8k2 safety edge
2 = sensitive edge NC
3 = 4k1 safety edge
(two safety edges in parallel)
Defines the situations in which the intervention of
the safety edge connected to the EDGE/STOP
inputs should be evaluated.
0 = EDGE/STOP input status evaluated only
during the closing manoeuvre
1 = EDGE/STOP input status evaluated during
iE.D.
both the closing and opening manoeuvres
ATTENTION !
STOP input during an opening manoeuvre results
in a brief reversal; during a closing manoeuvre,
on the other hand, it results in a full opening
manoeuvre.
Edge test
tE.D.
0 = off
1 = on
Defines the behaviour of the FLASH output
0 = output always active during opening and closing
manoeuvres
1 = output flashing during opening and closing
manoeuvres
2 = output always active with barrier in open position
3 = electrical lock (12V); before performing the
opening manoeuvre, the output is activated for
the time set in the
(
ADV
menu)
4 = magnetic lock (24V); output active when the
barrier is closed, the
parameter
FP.r.
time before starting the opening manoeuvre.
ATTENTION !
with 24VDC winding
5 = output active for fault signalling: motor
over-travel, encoder error, limit switch error,
three impacts were detected that prevented
arrival at the limit switch, number of manoeuvres
indicated by the parameter
exceeded.
NOTE: to deactivate an active signal, the equipment
must be powered off
DESCRIZIONE
intervention of the EDGE/
parameter
ELECT TIME
ELECT
TIME
specifies the demagnetisation
requires an external relay
CYCLE
SERVI
DEFAULT
MIN
MAX
1
0
1
0
0
1
0
0
3
1
0
3
0
0
1
0
0
1
1
0
5
UNITA'
