AL-KO AMS2 MAMMUT EINACHS Betriebsanleitung Seite 32

en
4. Then disengage the drives from the wheels.
The distance between the drive and the wheel must be at least 20 mm.
If the distance is smaller and/or if the drives cannot be moved off the wheels, the drives must
be retracted manually.
Remove the fuse and disconnect the battery!
5. Check whether all drives are correctly retracted.
6. Before starting to tow, release the handbrake of your caravan.
TROUBLESHOOTING
Malfunction
Flashing
Flashing or stays lit while mano-
euvring
Flashing or stays lit when not
manoeuvring
Flashing or lit up simultaneously
The remote control does not per-
form an LED test when switched
on
Initial start-up cannot be perfor-
med
32
Possible cause
Remote control batteries almost
empty
Drive batteries almost empty
Drive batteries empty.
System blocked.
The remote control was pro-
bably switched off too soon
Malfunction cannot be correc-
ted
Batteries flat
Remote control defective
Supply battery for the drives is
flat, defective, not connected
Fuse removed or defective
Remote control defective
Solution
Stop the manoeuvring process
and replace the remote control
batteries
Stop the manoeuvring process
and recharge the supply battery
Do not manoeuvre, there is a
danger of a total discharge of
the supply battery. Disengage
drives and charge the supply
battery
Repeat "Disengaging the drives
from the wheels"
Contact an AL-KO service
centre
Renew the batteries of the re-
mote control
Renew the remote control and
repeat the teach-in
Check the battery, charge, re-
new or connect it up as requi-
red
Check the fuse
Check the battery/remote con-
trol, renew
694 873_d
