Operating manual
• Provide sufficient space to ventilate the welding power source and access the controls.
• Do not use in an area with conductive metal dust.
• The welding power source should be protected from heavy rain and not exposed to direct sunlight.
• The equipment is IP23S protection degree, meaning :
- protection against access to dangerous parts of solid bodies with diam >12.5 mm and,
- protection against rain directed at 60° to the vertical when the moving parts of the device are not yet in operation.
This equipment can therefore be stored outdoors in accordance with protection class IP23S.
Stray welding currents can destroy earthing conductors, damage electrical equipment and devices and cause component parts
to overheat leading to fires.
- All welding connections must be firmly secured and regularly checked!
- Make sure that the item's attachment is firm and secure, without any electrical problems!
- Join together or suspend any electrically conductive parts of the welding source such as the frame, trolley and lifting systems so that they are
insulated!
- Do not place other equipment such as drills or grinding devices etc. on the welding source, trolley, or lifting systems unless they are insulated!
- Always place welding torches or electrode holders on an insulated surface when not in use!
Power cables, extension cables and welding cables should be fully unwound to avoid overheating.
The manufacturer assumes no responsibility for damage to persons or objects caused by improper and dangerous use of this
equipment.
MAINTENANCE / RECOMMENDATIONS
• Maintenance should only be carried out by a qualified person. Annual maintenance is recommended.
• Switch off the power supply by pulling the plug and wait two minutes before working on the equipment.. Inside the macine, the
voltages and currents are high and dangerous.
• Regularly remove the cover and blow out any dust. Take advantage of the opportunity to have the electrical connections checked with an insulated
tool by a qualified professional.
• Regularly check the condition of the power cord. If the power cable is damaged, it must be replaced by the manufacturer, the after sales service team
or an equally qualified person to avoid any danger.
• Leave the welding power source vents free for air intake and outflow.
• Do not use this welding power source for thawing pipes, recharging batteries/storage batteries or starter motors.
INSTALLATION - USING THE PRODUCT
Only experienced persons, authorised by the manufacturer, may carry out the installation. During installation, ensure that the power source is
disconnected from the mains. Series or parallel power source connections are not allowed. It is recommended to use the welding cables supplied with
the unit in order to obtain the best performance.
DESCRIPTION
This machine is a single-phase power source for semi-automatic, software-supported welding (MIG or MAG), coated electrode welding (MMA) and
refractory electrode welding (TIG). This machine will take Ø 200 and 300 mm wire reels.
DESCRIPTION OF THE EQUIPMENT (I)
1- Gas connector
2- Cable gland (mains cable)
3- ON / OFF switch
4- Reel support
5- USB connector
6- Rocker switch wire feed / gas purge
HUMAN-MACHINE INTERFACE (HMI)
Please read the Human Machine Interface (HMI) which forms part of the equipment's user literature.
HMI
24
Translation of the original
instructions
7- Wirefeed motor
8- MMI
9- Push-Pull torch connector
10- Euro connector
11- Positive polarity plug
12- Negative polarity plug
13- Polarity reversal cable
NEOPULSE 220 C XL
