2.3 LOCAL MODE (AD-HOC)
When turned on for the first time, the Wifi box is in
local mode (Wifi LED flashes blue) and creates a Wifi
network that can be connected to by a mobile phone.
▪
Name of the network (SSID): FENIX-XXXX
▪
Password: 123456789
Local mode persists until a home Wifi network is config-
ured via the FENIX TFT Wifi mobile application
When configured, the local mode can also be used to
control the panel directly by the mobile application,
without Internet. Pressing the Wifi button for more than
3s, switches the panel to local mode waiting for the
phone to connect. If there is no connection or the phone
is disconnected, the local mode is terminated automati-
cally after 3 minutes and the panel is reconnected back
.
to the home network
2.4 CONNECTION TO HOME WIFI NETWORK
The «FENIX TFT Wifi» app is available at App Store
and Google Play. When starting the application, you must
create or log in to the user account which the panel will
be connected to.
The procedure for connecting a new Wifi device can be
found directly in the application. Open Settings (top left
icon) and follow the «Start Tutorial» wizard
Connection Pairing your device
Log in or create aacount
Open WiFi menu on your device
Setting—WiFi
Connect your phone to WiFi device
For easy panel pairing with the user account, the Wifi
box is equipped with a unique QR code that can be
scanned directly from the application
.
2.5
The Wifi box has three different coloured LEDs, three
buttons and a sound signal to turn the panel on and off.
The buttons and the LED control lights are located on the
Wifi box side (accessible even after the panel is mount-
).
ed
ON/OFF button
The ON/OFF button is used to turn the panel on and off
and to activate RF pairing
Short press
▪
Switching the panel on or off (see sec. 2.7
Long press (5s)
Starts RF pairing mode (see sec. 4.3)
Wifi button
No function is allocated to a short press
Longer press (3s)
▪
Switching to the local mode (see sec. 2.3)
Timer button
▪
Short press activates / deactivates the Timer mode
(see sec. 3.3)
.
Adding new device
Click on the button above
and add your device
23
WIFI BOX CONTROLS
LED indication of heating
LED indication of RF commun.
LED indication of Wifi status
Timer button
Wifi button
ON/OFF button
.
)
