steute swView 868 Betriebsanleitung Seite 6

swView 868/915
//
Betriebsanleitung / Feldstärkemessgerät
Operating instructions / Field strength testing tool
English
FCC/IC Regulatory Information
This device complies with part 15 of the FCC rules and RSS-210 of IC
rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interfe-
rence that may cause undesired operation.
Modifications not expressly approved by this company could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These li-
mits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interfe-
rence will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encou-
raged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Exposure to Radio Frequency (RF) Signals
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment must provide a sepa-
ration distance of at least 20 cm from all persons and must not be co-
located or operating in conjunction with any other antenna or trans-
mitter. Not Authorized modification could void authority to use this
equipment.
Notices
The transmission of one switching command from transmitter to re-
ceiver lasts approx. 80 to 100 ms on basis of the steute Wireless data
transmission. The switching signal of a transmitter must not be gene-
rated in shorter time sequences otherwise this signal will be sup-
pressed. The devices can be operated registration- and license-free
on the territory of the EC, USA, Canada Switzerland and Cyprus. The
use in other countries must be explicitely clarified! Subject to techni-
cal modifications. Reconstruction and alterations at the switch are not
allowed. Moreover steute does not assume any lia-bility for recom-
mendations made or implied by this description. From this description
new claims for guarantee, warranty or liability cannot be derived bey-
ond the general terms and conditions of delivery.
Technical data
Standards EN 60947-5-1; EN 61000-6-2; EN 301 489-1;
EN 301 489-3; EN 300 220-1, EN 300 220-2
Enclosure Thermoplastic ABS (Acryl-Butadien-Styrol)
UL 94-HB
Degree of protection
IP 44 to IEC/EN 60529
Protocol
steute Wireless
Display LCD 3x16 ASCII Zeichen
Switching frequency approx. 1200 telegrams depeding on the mode
< 20 mW depeding on the mode
Transmission power
Modulation process FSK
66,67 kbps
Data rate
200 kHz
Bandwidth channel
Frequency 868,3 MHz/915 MHz
Sensing range max. 400 m outside,
max. 40 m inside
Power supply 2AA batteries (replaceable)
Standby after 5 min.
Battery life Standby: approx. 3 years, active mode
(Continuous operation): approx. 12 days
Ambient temperature -20 °C ... +85 ºC
Approvals FCC: XK5-RFRXSW915
IC: 5158A-RFRXSW915
