Repeat mode
The received telegrams are repeated and amplified in the repeat
mode.
Id No.
*REPEAT-MODUS*
000116*OFF*008
0003EF*_ON*051
swView
1. ID No.: ID number of the received telegrams
2. Switching status: ON or OFF
3. Number of telegrams: Number of occured telegrams with
this ID Nro
Rescan mode
The characteristics of the selected transmitter are displayed in the
rescan mode.
Push-button No. T0 ... 4
Switching status
RSSI
RESCAN 0003DF
T1*OFF*086% REC
RPT*ERR*2,90V
swView
Battery status
Error
Repeat
1. ID No.: The aelected ID number
2. No. of push-button: The pressed number of push-button is dis-
3. Switching status: ON or OFF
4. RSSI: Signal strength in percent
5. Confirmation: »REC« is displayed, if a receiver has transmitted a
confirmation telegram
6. Battery status: Battery condition of transmitter. With self-sufficient
7. Error: »ERR« is displayed, when the last transmission has not pro-
Switching status
perly been confirmed.
Number of telegrams
8. Repeat: The received telegramm has been repeated. This happens if
0-999
Radio link
Telegrams with selected ID No. are transmitted in radio link.
1. Press LINK push-button: Telegram with switching status »ON« is
2. Release LINK push-button: Telegram with switching status »OFF« is
Id No.
3. ID No.: The selected ID number
Confirmation
4. OUTPUT: Displays which switching status has been transmitted
5. Switching status: ON or OFF
6. Confirmation: »ANSWER« is displayed, if a receiver has transmitted
played with transmitters with multiple push-buttons. With self-suf-
ficient transmitters »T1« is displayed.
transmitters »-----« is displayed
the transmitter receives no confirmation from the receiver.
transmitted
transmitted
Output
RADIO 000454
OUTPUT: OFF
ANSWER
swView
Confirmation
a confirmation telegram.
»NO ANSWER« is displayed, if a receiver has not
transmitted a confirmation telegram.
Id No.
Switching status
