Symbol
Meaning
High speed
Switching On
Switching Off
On/Off switch lock-on
Releasing the lock-on function of
the On/Off switch
Prohibited action
Permitted action
Next step of action
P
Rated power input
1
P
Output power
2
n
Rated speed
n
Speed control adjustment
v
l = Grinder spindle length
d
1
d
= Grinder spindle diameter
l
1
D = Max. grinding disc diameter
d
2
d
= Inner disc diameter
D
2
Speed preselection
Restarting Protection
The restarting protection feature
prevents uncontrolled restarting
of the machine after an interrup-
tion in the power supply.
To restart the operation, switch
the On/Off switch to the Off po-
sition and start the machine
again.
Additional information
Surface grinding
Grinding/sanding with sanding
sheet
Weight according to
1
EPTA-Procedure 01:2014 with vi-
bration-damping auxiliary handle
1 619 P12 664 • 16.6.15
Symbol
Meaning
Weight according to
2
EPTA-Procedure 01:2014 with
standard-auxiliary handle
/II
Symbol for protection class II
(completely insulated)
L
Sound power level
wA
L
Sound pressure level
pA
K
Uncertainty
a
Vibration total value
h
Delivery Scope
Angle grinder, protection guard, auxiliary handle.
Special protection guards, application tools and
other accessories shown or described are not part
of the standard delivery scope.
A complete overview of accessories can be found
in our accessories program.
Intended Use
The machine is intended for roughing metal, stone
and ceramic materials and for drilling tiles.
For cutting with bonded abrasives, a special cut-
ting guard (accessory) must be used.
When cutting in stone, provide for sufficient dust
extraction.
Together with the hand guard (accessory), the ma-
chine can be used for brushing and grinding/sand-
ing with elastic sanding plates.
The machine is suitable only for working without
water.
Technical Data
The technical data of the machine are listed in the
table on page 21.
The values given are valid for a nominal voltage [U]
of 230 V. For different voltages and models for spe-
cific countries, these values can vary.
English | 17
