This manual is giving information about a correct assembly, use and maintenance of the hose reels in
order to prevent accidents.
The hose reel has been designed in conformity to the present EEC rules and UK standards and name-
ly:
- UNI EN ISO 12100:2010 and BS EN ISO 12100:2010 Safety of machinery - General principles for
design
Risk assessment and risk reduction (ISO 12100:2010);
- UNI EN ISO 13857:2020 and BS EN ISO 13857:2019 Safety of machinery - Safety distances to
prevent hazard zones being reached by upper and lower limbs (ISO 13857:2019);
- UNI EN ISO 9539:2010 and BS EN ISO 9539:2010+A1:2013 Gas welding equipment. Materials for
equipment used in gas welding, cutting and allied processes
- UNI EN ISO 3821:2010 and BS EN ISO 3821:2019 Gas welding equipment. Rubber hoses for
welding, cutting and allied processes.
The equipment must be used in accordance with the instructions contained in this manual and it is
guaranteed for a period of 18 months from date of manufacture. Warranty does not cover flexible hoses,
seals, all wear parts and all parts which are faulty after incorrect use, incorrect installation or mainte-
nance, maintenance carried out by unauthorized personnel, transport damages, or for circumstances
not concerning manufacturing defects. The manufacturer disclaims any responsibility for any damage,
that may directly or indirectly, derive to persons or property in consequence to the not observed requi-
rements specified in this instruction manual and especially the warnings regarding installation, use and
maintenance.
The hose reels models OVP are made of hot galvanized moulded steel and painted with electrostatic
polyester powder system in order to guarantee a long life of the product.
The hose rolling is done automatically by a spring made of high quality iron, incorporated in the drum.
The stop can be done at any desired length, through an automatic locking device.
The hose reels supplied without hose are provided with the unloaded spring. Follow the instruc-
tions described at the chapter "HOSE ASSEMBLY".
The automatic device stopping the hose works on an area corresponding to 1/3 turn of the drum.
To release the hose, put a light traction on it.
It is important always to keep the hose back when you rewind it, in order to avoid
damages to the machine, injuries to people or to surrounding things.

5 - INTENDED USE OF THE MACHINE

All the hose reels have to be used only for distributing propane or methane and in the version
without hose even for oxygen. It is forbidden to use the machine for any other kind of fluid.
We decline any responsibility for anomalies or dangers which could arise by a hose assembly with
characteristics and uses different from the ones described herein. Avoid to get on the machine or to lay
any kind of material on it. Check periodically the correct operation of the hose reel, and control that the
couplers are well locked and there are no fluid losses. Close the feeding of oxigen and gas at the
shift end and when the hose reel is not used for longer than 30 minutes to avoid damages during
non-working hours.
Use of the hose reel is not permitted in potential explosive environments (ATEX).
ENGLISH - Translated from Italian

1 - GENERAL RULES APPLIED

2 - WARRANTY

3 - DESCRIPTION

4 - OPERATION
