IMPORTANT! Any installation operation shall be carried out by a suitably
trained staff, following carefully the information given in this manual.
Check the packaging at the reception of the goods and store only at a dry place. Verify that
the device has not been damaged during transport or storage operations. Make sure you
receive all the components. Ask the manufacturer for any possible missing component.
The hose reel has to be wall mounted at a minimum height of the floor of 2.50 m in
order to prevent accidents during work operations.
Considering the hose reel weight and dimensions, its movement requires the use of lifter
devices.In particular cases it is possible to mount it on the floor or on other machines as
accessory, only if complete with a fixed support. The hose-guide arms can be fixed in three
different positions according to the hose reel installation (see pictures A-B-C p.28).
Mount the hose reel in fixed position or with revolving stand (OPTIONAL) on stiff and consi-
stent walls using 4 dowels of 10 mm diameter. (See drawing p.28)
WARNING! The manufacturer declines any responsibility for injuries to people or da-
mages to things caused by a wrong assembly of the hose reel.
WARNING: Risk of explosion!
Do not lubricate the swivel joints and the seals for Oxigen and Acetylene with oil and
grease. Use lubricant (BAM) approved only.
Connect the hose reel to the line by the clamps in dotation.
Fit some safety valves IN CONFORMITY WITH THE "EN 730" RULE on the piping network,
before the connection to the swivel joints and to the end of the hose, to prevent a back-fire
and a back-gas. According to the rules, put a ball-tap on the feeding line of the hose reel
in order to make the maintenance operations easier and as a safety valve for dangerous
situations.

8 - INSTALLATION

9 - LINK
