Inhaltszusammenfassung für Dimplex WPL 80IRR

  • Seite 1 All manuals and user guides at all-guides.com Montage- und Gebrauchsanweisung Installation and Operating Instructions Instructions d’installation et d’utilisation WPL 80IRR WPL 120IRR Reversible Reversible Pompe à chaleur Luft/Wasser- Air-to-Water air-eau réversible Wärmepumpe für Heat Pump for pour installation Innenaufstellung Indoor Installation intérieure...
  • Seite 2 All manuals and user guides at all-guides.com...
  • Seite 3: Inhaltsverzeichnis

    All manuals and user guides at all-guides.com Inhaltsverzeichnis Bitte sofort lesen .......................... D-2 1.1 Wichtige Hinweise ..........................D-2 1.2 Gesetzliche Vorschriften und Richtlinien ....................D-2 1.3 Energiesparende Handhabung der Wärmepumpe .................D-2 Verwendungszweck der Wärmepumpe ..................D-2 2.1 Anwendungsbereich ..........................D-2 2.2 Arbeitsweise ............................D-3 Lieferumfang..........................
  • Seite 4: Bitte Sofort Lesen

    All manuals and user guides at all-guides.com Bitte sofort lesen 1.3 Energiesparende Handhabung der Wärmepumpe 1.1 Wichtige Hinweise Mit dem Kauf dieser Wärmepumpe tragen Sie zur Schonung der Umwelt bei. Die Voraussetzung für eine energiesparende Be- ACHTUNG! triebsweise ist die richtige Auslegung der Wärmequellen- und Das Gerät ist nicht für Frequenzumrichterbetrieb geeignet.
  • Seite 5: Arbeitsweise

    All manuals and user guides at all-guides.com Lieferumfang 2.2 Arbeitsweise Heizen 3.1 Grundgerät Umgebungsluft wird vom Ventilator angesaugt und dabei über den Verdampfer (Wärmetauscher) geleitet. Der Verdampfer Die Wärmepumpe wird in Kompaktbauweise geliefert und enthält kühlt die Luft ab, d.h. er entzieht ihr Wärme. Die gewonnene unten aufgeführte Bauteile.
  • Seite 6: Schaltkasten

    All manuals and user guides at all-guides.com Transport 3.2 Schaltkasten Der Schaltkasten befindet sich in der Wärmepumpe. Nach Ab- ACHTUNG! nahme der unteren Frontabdeckung und dem Lösen der sich Die Wärmepumpe darf beim Transport nur bis zu einer Neigung von 45° rechts oben befindenden Befestigungsschraube kann der (in jeder Richtung) gekippt werden.
  • Seite 7: Aufstellung

    All manuals and user guides at all-guides.com Aufstellung Montage 5.1 Allgemein 6.1 Allgemein Das Gerät ist grundsätzlich in Innenräumen auf einer ebenen, An der Wärmepumpe sind folgende Anschlüsse herzustellen: glatten und waagrechten Fläche aufzustellen. Dabei sollte der Zu-/Abluft Rahmen rundum dicht am Boden anliegen, um eine geeignete Vor-/Rücklauf der Heizungsanlage Schallabdichtung zu gewährleisten.
  • Seite 8: Heizungs- Und Warmwasser-Anschluss

    All manuals and user guides at all-guides.com Frostschutz Bei Wärmepumpen, die frostgefährdet aufgestellt sind, sollte eine manuelle Entleerung (siehe Bild) vorgesehen werden. So- fern Regler und Heizungsumwälzpumpe betriebsbereit sind, ar- beitet die Frostschutzfunktion des Reglers. Bei Außerbetrieb- nahme der Wärmepumpe oder Stromausfall ist die Anlage zu entleeren.
  • Seite 9: Inbetriebnahme

    All manuals and user guides at all-guides.com Inbetriebnahme Wärmequellen- max. Temperaturspreizung temperatur zwischen Heizungsvor- und 7.1 Allgemein Rücklauf -20 °C -15 °C Um eine ordnungsgemäße Inbetriebnahme zu gewährleisten, -14 °C -10 °C sollte diese von einem vom Werk autorisierten Kundendienst -9 °C -5 °C durchgeführt werden.
  • Seite 10: Reinigung / Pflege

    All manuals and user guides at all-guides.com Reinigung / Pflege 8.3 Reinigung Luftseite Luftkanäle, Verdampfer, Lüfter und Kondensatablauf sind vor der 8.1 Pflege Heizperiode von Verunreinigungen (Blätter, Zweige usw.) zu rei- nigen. Dazu ist die Wärmepumpe an der Frontseite zuerst unten Vermeiden Sie zum Schutz des Lackes das Anlehnen und Able- und dann oben zu öffnen.
  • Seite 11: Geräteinformation

    All manuals and user guides at all-guides.com 11 Geräteinformation Geräteinformation für Luft/Wasser-Heiz-Wärmepumpen Typ- und Verkaufsbezeichnung WPL 80IRR WPL 120IRR Bauform Ausführung Reversibel Reversibel Schutzart nach EN 60 529 für Kompaktgerät bzw. Heizteil IP 21 IP 21 Aufstellungsort Innen Innen Leistungsangaben...
  • Seite 12: Garantieurkunde

    Deutschland: in unser Eigentum über. Die Garantiezeit für Nachbesserungen und Ersatzteile endet mit dem Ablauf der ursprünglichen Garan- Glen Dimplex Deutschland GmbH tiezeit für das Gerät. Die Garantie erstreckt sich nicht auf leicht Kundendienst Systemtechnik zerbrechliche Teile, die den Wert oder die Gebrauchstauglichkeit Am Goldenen Feld 18 des Gerätes nur unwesentlich beeinträchtigen.
  • Seite 13 All manuals and user guides at all-guides.com Table of contents Please Read Immediately ......................E-2 1.1 Important Information..........................E-2 1.2 Legal Regulations and Directives ......................E-2 1.3 Energy-Efficient Use of the Heat Pump ....................E-2 Purpose of the Heat Pump ......................E-2 2.1 Application ..............................
  • Seite 14: Please Read Immediately

    All manuals and user guides at all-guides.com Please Read 1.3 Energy-Efficient Use of the Immediately Heat Pump With the purchase of this heat pump you are helping to protect the environment. A prerequisite for energy-efficient operation is 1.1 Important Information the correct design of the heat source system and heating (radia- tors and circulation pump) or cooling system.
  • Seite 15: Operating Principle

    All manuals and user guides at all-guides.com Scope of Delivery 2.2 Operating Principle Heating 3.1 Basic Device Surrounding air is drawn in by the ventilator and fed via the evap- orator (heat exchanger). The evaporator cools the air, i.e. it ex- The heat pump is of compact design and is supplied complete tracts heat from it.
  • Seite 16: Switch Box

    All manuals and user guides at all-guides.com Transport 3.2 Switch Box The switch box is located in the heat pump. It can be swung out ATTENTION! after removing the lower front cover and loosening the fastening When transporting the heat pump, ensure that it is not tilted more than screw located in the upper right-hand corner.
  • Seite 17: Set-Up

    All manuals and user guides at all-guides.com Set-up Installation 5.1 General Information 6.1 General Information The unit must be installed indoors on a level, smooth and hori- The following connections need to be established on the heat zontal surface. The entire base of the frame should lie directly on pump: the floor to ensure a good soundproof seal.
  • Seite 18: Heating And Hot Water Connection

    All manuals and user guides at all-guides.com Antifreeze A method of manual drainage (see illustration) should be pro- vided for heat pumps which are exposed to frost. The antifreeze function of the heat pump controller is active whenever the con- troller and the heat circulating pump are ready for operation.
  • Seite 19: Start-Up

    All manuals and user guides at all-guides.com Start-up Heat source Max. temperature spread temperature between heating flow and return 7.1 General Information flow From -20 °C -15 °C To ensure that start-up is performed correctly, it should only be -14 °C -10 °C carried out by an after-sales service technician authorised by the -9 °C...
  • Seite 20: Maintenance / Cleaning

    All manuals and user guides at all-guides.com Maintenance / Cleaning 8.3 Cleaning the Air System Air ducts, evaporator, ventilator and condensate outflow should 8.1 Maintenance be cleaned of contamination (leaves, twigs, etc.) before each new heating period. Do this by opening the front of the heat To protect the paintwork, avoid leaning anything against the de- pump.
  • Seite 21: Device Information

    All manuals and user guides at all-guides.com 11 Device Information Device information for air-to-water heat pumps for heating purposes Type and order code WPL 80IRR WPL 120IRR Design Model Reversible Reversible Degree of protection according to EN 60 529 for compact devices...
  • Seite 22 All manuals and user guides at all-guides.com E-10...
  • Seite 23 All manuals and user guides at all-guides.com Table des matières A lire immédiatement !........................F-2 1.1 Remarques importantes ......................... F-2 1.2 Dispositions légales et directives......................F-2 1.3 Utilisation de la pompe à chaleur pour économiser de l'énergie ............F-2 Utilisation de la pompe à chaleur ....................F-2 2.1 Domaine d’utilisation..........................
  • Seite 24: Lire Immédiatement

    All manuals and user guides at all-guides.com A lire immédiatement ! Les enfants doivent être surveillés pour éviter qu'ils ne jouent avec l'appareil. 1.1 Remarques importantes 1.3 Utilisation de la pompe à chaleur pour économiser de ATTENTION ! l'énergie L’appareil ne convient pas au mode convertisseur de fréquence. ATTENTION ! En utilisant cette pompe à...
  • Seite 25: Fonctionnement

    All manuals and user guides at all-guides.com Fourniture La pompe à chaleur est appropriée en mode refroidissement pour des températures de l’air allant de +15 °C à +40 °C. Elle peut être utilisée pour un refroidissement silencieux et dyna- 3.1 Appareil de base mique.
  • Seite 26: Boîtier Électrique

    All manuals and user guides at all-guides.com Transport 3.2 Boîtier électrique Le boîtier électrique est monté dans la pompe à chaleur. Le boî- ATTENTION ! tier électrique peut être rabattu après avoir retiré l’habillage fron- Lors du transport, l’angle d’inclinaison de la pompe à chaleur ne doit pas tal inférieur et dévissé...
  • Seite 27: Installation

    All manuals and user guides at all-guides.com Installation Montage 5.1 Remarques d’ordre général 6.1 Remarques d’ordre général En règle générale, l'appareil doit être installé à l'intérieur, sur une Les raccordements suivants doivent être réalisés sur la pompe à surface plane, lisse et horizontale. Ici, le châssis de la pompe à chaleur : chaleur doit adhérer au sol sur toute sa circonférence afin de ga- Aspiration/évacuation d’air...
  • Seite 28: Raccordement Chauffage Et Eau Chaude

    All manuals and user guides at all-guides.com Protection antigel Dans le cas de pompes à chaleur exposées au gel, une vidange manuelle du circuit de chauffage (voir Fig.) devrait être prévue. La fonction de protection antigel du régulateur fonctionne dès que le régulateur et les circulateurs de chauffage sont opération- nels.
  • Seite 29: Mise En Service

    All manuals and user guides at all-guides.com Mise en service Température Différence de température max. de départ entre circuits départ et retour du 7.1 Remarques d’ordre général chauffage à -20 °C -15 °C Pour garantir une mise en service en règle, cette dernière doit -14 °C -10 °C être effectuée par un service après-vente agréé...
  • Seite 30: Nettoyage / Entretien

    All manuals and user guides at all-guides.com Nettoyage / entretien 8.3 Nettoyage côté air Les conduits d’air, l’évaporateur, l’aérateur et l’écoulement des 8.1 Entretien condensats doivent être nettoyés de leurs impuretés (feuilles, branches etc.) avant la période de chauffage. Ouvrir la façade de Il faut éviter d’appuyer ou de déposer des objets sur l’appareil la pompe à...
  • Seite 31: Informations Sur Les Appareils

    All manuals and user guides at all-guides.com 11 Informations sur les appareils Informations sur les pompes à chaleur air/eau pour chauffage Désignation technique et commerciale WPL 80IRR WPL 120IRR Forme Version réversible réversible Type de protection selon EN 60 529 pour app. compact ou élt. de chauffe...
  • Seite 32 All manuals and user guides at all-guides.com F-10...
  • Seite 33 Anhang / Appendix / Annexes Maßbilder / Dimension Drawings / Schémas cotés..............A-II 1.1 Maßbild / Dimension Drawing / Schéma coté WPL 80IRR..............A-II 1.2 Maßbild / Dimension Drawing / Schéma coté WPL 120IRR..............A-III Diagramme / Diagrams / Diagrammes..................A-IV 2.1 Heizbetrieb / Heating Operation / Mode chauffage WPL 80IRR............A-IV...
  • Seite 34: Maßbilder / Dimension Drawings / Schémas Cotés

    All manuals and user guides at all-guides.com 1 Maßbilder / Dimension Drawings / Schémas cotés 1.1 Maßbild / Dimension Drawing / Schéma coté WPL 80IRR A-II...
  • Seite 35: Maßbild / Dimension Drawing / Schéma Coté Wpl 120Irr

    All manuals and user guides at all-guides.com 1.2 Maßbild / Dimension Drawing / Schéma coté WPL 120IRR A-III...
  • Seite 36: Diagramme / Diagrams / Diagrammes

    All manuals and user guides at all-guides.com 2 Diagramme / Diagrams / Diagrammes 2.1 Heizbetrieb / Heating Operation / Mode chauffage WPL 80IRR A-IV...
  • Seite 37: Kühlbetrieb / Cooling Operation / Mode Refroidissement Wpl 80Irr

    All manuals and user guides at all-guides.com 2.2 Kühlbetrieb / Cooling Operation / Mode refroidissement WPL 80IRR...
  • Seite 38: Heizbetrieb / Heating Operation / Mode Chauffage Wpl 120Irr

    All manuals and user guides at all-guides.com 2.3 Heizbetrieb / Heating Operation / Mode chauffage WPL 120IRR A-VI...
  • Seite 39: Kühlbetrieb / Cooling Operation / Mode Refroidissement Wpl 120Irr

    All manuals and user guides at all-guides.com 2.4 Kühlbetrieb / Cooling Operation / Mode refroidissement WPL 120IRR A-VII...
  • Seite 40: Stromlaufpläne / Circuit Diagrams / Schémas Électriques

    All manuals and user guides at all-guides.com 3 Stromlaufpläne / Circuit Diagrams / Schémas électriques 3.1 Steuerung / Control / Commande A-VIII...
  • Seite 41: Last / Load / Charge

    All manuals and user guides at all-guides.com 3.2 Last / Load / Charge A-IX...
  • Seite 42: Anschlussplan / Circuit Diagram / Schéma Électrique

    All manuals and user guides at all-guides.com 3.3 Anschlussplan / Circuit Diagram / Schéma électrique...
  • Seite 43: Legende / Legend / Légende

    All manuals and user guides at all-guides.com 3.4 Legende / Legend / Légende Kurbelwannenheizung Verdichter Crankcase heater, compressor Chauffage à carter compresseur Pressostat Abtauende Defrost end controller Pressostat fin de dégivrage Pressostat Kondensationsdruck Condensation pressure switch Pressostat pression condensation Pressostat Hochdruck High-pressure switch Pressostat haute pression Pressostat Niederdruck...
  • Seite 44: Hydraulisches Prinzipschema / Hydraulic Plumbing Diagram / Schéma Hydraulique

    All manuals and user guides at all-guides.com 4 Hydraulisches Prinzipschema / Hydraulic Plumbing Diagram / Schéma hydraulique 4.1 Darstellung / Schematic View / Représentation A-XII...
  • Seite 45: Legende / Legend / Légende

    All manuals and user guides at all-guides.com 4.2 Legende / Legend / Légende Absperrventil Shutoff valve Robinet d’arrêt Überstromventil Overflow valve Vanne de trop-plein Sicherheitsventilkombination Safety valve combination Groupe de valves de sécurité Umwälzpumpe Circulating pump Circulateur Ausdehnungsgefäß Expansion vessel Vase d´expansion Raumtemperaturgesteuertes Ventil Room temperature-controlled valve...
  • Seite 46: Konformitätserklärung / Declaration Of Conformity / Déclaration De Conformité

    All manuals and user guides at all-guides.com 5 Konformitätserklärung / Declaration of Conformity / Déclaration de conformité A-XIV...
  • Seite 47 All manuals and user guides at all-guides.com A-XV...
  • Seite 48 All manuals and user guides at all-guides.com Heizungsfachbetrieb / Your local heating contractor / Cachet de l’installateur Deutschland Österreich BBT Thermotechnik GmbH Buderus Austria Heiztechnik GesmbH D-35573 Wetzlar Karl-Schönherr-Straße 2 www.heiztechnik.buderus.de AT-4600 Wels info@heiztechnik.buderus.de www.buderus.at office@buderus.at Schweiz Frankreich Buderus Heiztechnik AG Buderus Chauffage SAS Netzibodenstraße 36 4 rue Wilhelm Schaeffler...
