If the module is used at the end of the cable line, the ends of the two
flat cables should be secured by means of shrink wraps (order no.
E70113).
Cover the sockets not used with the enclosed protective caps to
guarantee the protection rating IP67.
If required, you can ground the module via the earth springs (1*).
AC2417
lower part with profiled
slots for flat cable
1* earth springs
118
AS-i
ext. voltage
1 2
1*
LED 4
1*
fixture infrared adapter
4,5
LEDs 1
LED AUX
LED 3
107
LED 2 AS-i
3
7
