Operation
Check the safe functioning of the unit. Display by LEDs:
• LED 1 yellow:
• LED 2 green:
• LED 3 red is lit:
• LED 3 red flashes:
• LED 4:
• LED AUX green:
Maintenance
The operation of the module is maintenance-free.
Always exchange the upper part and lower part at the same time.

Technical data

You can download the data sheet from the Internet address
www.ifm-electronic.com if required.
Installation
Disconnect the installation from power before mounting.
Select a plane mounting surface. The bottom of the module
must lie flat on the mounting surface.
1. Screw the lower part onto the mounting surface (mounting holes
mounting screws not supplied).
2. Insert the AS-i standard cable (yellow) and the cable for external
power supply (black). Ensure correct positioning of the cable in the
profiled slot.
3. Put the upper part on the lower part and tighten the screws
(screws supplied).
4. Screw the upper part onto the mounting surface (mounting hole
mounting screw not supplied).
6
output switched
AS-i supply voltage o.k.
AS-i communication error, slave does not
participate in the "normal" exchange of
data, e.g. slave address 0
periphery fault, e.g. actuator supply
overloaded or shorted
infrared reciever
external voltage o.k.
1 ,
2
3
,
