Fischer Panda 60i PMS parallel Handbuch Seite 95

Störungen am Generator
SPN FMI FaultCheckDescription
1244 15 short circuit to battery in the high side of the pressure control
valve
1244 17 short circuit to ground in the high side of the pressure control
valve
1244 16 short circuit to battery of pressure control valve output
1244 18 short circuit to ground of the pressure control valve output
1244 4 signal range check high error of pressure control valve AD-
channel
1244 3 signal range check low error of pressure control valve AD-
channel
108 0 Ambient air pressure sensor range chack max-error
108 1 Ambient air pressure sensor range check min-error
108 3 fault check max signal range violated for ambient air pressure
sensor
108 4 fault check min signal range violated for ambient air pressure
sensor
102 0 Physical Range Check high for air pressure at the upstream of
intake valve sensor
102 1 Physical Range Check low for air pressure at the upstream of
intake valve sensor
102 0 Plausibility Check for air pressure at the upstream of intake
valve sensor
102 1 Plausibility Check for air pressure at the upstream of intake
valve sensor
102 3 Diagnostic fault check for SRC high in air pressure upstream of
intake valve sensor
102 4 Diagnostic fault check for SRC low in air pressure upstream of
intake valve sensor
23906 5 open load of pre-supply pump output
23906 12 Over temperature error on ECU powerstage for Pre supply
pump
23906 3 short circuit to battery of pre-supply pump output
23906 4 short circuit to ground of pre-supply pump output
23613 0 maximum positive deviation of rail pressure exceeded
23613 24 leakage is detected based on fuel quantity balance
23613 1 If the rail pressure governor deviation Rail_pDvt falls below the
limiting value Rail_pMeUnDvtMin_CUR and if the CP3 delivery
quantity MeUn_dvolSet falls to the threshold
Rail_MeUnMon.dvolSetMin_C (-350 mm^3/s) an error will be
detected.
2.11.17
Possible Causes
Over boost condition, maybe wastgate blocked
Under boost, maybe turbocharger defective
PIntkVUss pressure sensor or EnvP sensor misadjusted or
defect
PIntkVUss pressure sensor or EnvP sensor misadjusted or
defect
wiring harness or component
wiring harness or component
1.) Leakage in the high pressure section
2.) injection nozzle stuck in open position
3.) worn high pressure pump
4.) worn injector (to high injector backflow quantity)
5.) fuel filter clogged up
6.) PSP (electric pre-supply pump) output too low
Maladjusted rail pressure sensor, defective high pressure pump,
leakage,
Possible error in the low pressure stage, Backflow too low
1.) Metering unit is stuck in open position
2.) zero delivery throttle clogged up
3.) metering unit without power due to electrical error.
4.) pressure after zero-delivery throttle too high.
Kapitel/Chapter 8: Störungen am Generator - Seite/Page 95
