Maintenance of the air filter (Fig. 20)
A soiled air filter will reduce the performance of the
engine because it will prevent enough air getting to
the carburetor. It is therefore imperative that regular
checks are made.
The air filter should be checked every 25 hours and
cleaned if required. If the air is very dusty the air filter
should be checked more regularly.
Unclip the air filter cover and remove the sponge filter
element. To avoid objects falling into the air intake,
replace the air filter cover. (Fig. 20).
Important: Never clean the air filter with petrol or in-
flammable cleaning agents. Clean the air filter with
compressed air or simply by knocking out any soiling.
Maintenance of the spark plug (Fig. 21)
Check the spark plug for dirt and grime after 10 hours
of operation and if necessary clean it with a copper
wire brush. Thereafter service the spark plug after
every 50 hours of operation.
Pull off the spark plug boot with a twist.
Remove the spark plug (10) with a spark plug wrench.
Using a feeler gauge, set the gap to 0.75 mm( 0.030").
Replace the spark plug (10) and take care not to pull
it too firmly.
Engine brake lever (Fig. 1)
The engine is equipped with a mechanical brake (3)
which has to be checked regularly. When releasing
the brake lever, the blade must come to a halt within
7 seconds. If this is not the case, the machine must
not be used. Contact an authorised specialist retailer.
Ensure that the machine is in a flawless condition for
its entire service life. Improper maintenance may lead
to life-threatening injuries.
Repairs
After any repair or maintenance work, check that all
safety-related parts are in place and in proper work-
ing order. All parts which may cause injury must be
kept where they are inaccessible to children or oth-
ers.
Important: In accordance with product liability legis-
lation we are not liable for any damages caused by
improper repairs or the use of spare parts that are not
original spare parts or parts approved by us.
In addition, we are also not liable for any damages
arising from improper repairs. Such work should be
performed by a customer services workshop or au-
thorized specialist. The same applies to accessory
parts.
Times of use
Please comply with statutory regulations, which may
vary from location to location.
Please provide the following information in the
event of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Engine data - type plate
Important note in the case of repairs:
When returning the mower for repair, for safety rea-
sons, ensure that it is free of oil and petrol when it is
sent to the service centre.
Spare parts / accessories
Lawn mower blade - Article no.: 7911200618
Engine oil - Article no.: 7850000025
Service information
With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
Wear parts*: spark plug, air filter, petrol filter, knife,
belt, battery
* may not be included in the scope of supply!
14. Disposal and recycling
Notes for packaging
Notes on the electrical and electronic equipment
act [ElektroG]
Waste electrical and electronic equipment
does not belong in household waste, but
must be collected and disposed of sepa-
rately!
• Old batteries or rechargeable batteries that are
not permanently installed in the old unit must be
removed before handing them in! Their disposal is
regulated by the battery act.
• Owners or users of electrical and electronic devic-
es are legally obliged to return them after use.
• The end user is responsible for deleting their per-
sonal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that
waste electrical and electronic equipment must not
be disposed of with household waste.
• Waste electrical and electronic equipment can be
handed in free of charge at the following places:
- Public disposal or collection points (e.g. munici-
pal works yards)
- Points of sale of electrical appliances (stationary
and online), provided that dealers are obliged to
take them back or offer to do so voluntarily.
www.scheppach.com
The packaging materials are recy-
clable. Please dispose of packaging
in an environmentally friendly man-
ner.
GB | 41
