The following data differ from the data as described in the PR 5610 Installation Manual:

Load cells

5.1
Load cell connection
Load cell supply
Load cell supply circuit
Max. load

Power Supply

5.2
Power voltage
Power consumption

Construction type

5.3
Steel housing with aluminium frontplate, foil sealed to IP 54.

Dimensions

5.4
Housing
Width
Height
Depth

Connectors

5.5
Screw terminals for load cells and options 1 - 3, DIN 5-pole f connector for external keyboard, DB 9 f connector
for Builtin interface.

Weight

5.6
Net weight
Shipping weight
18
ATA
all strain gauge cells, 6 or 4-wire connection possible.
U= ± 6 V ( I
max
12 / 20 VDC
≥ 75 Ω
230 V/ 115 V AC
14,5 W/ 19 VA
Dimensions
483 mm
133 mm
156 mm (195mm including front plate and rear cable support)
4,7 kg
8,7 kg
X6 System Weighing Controller
= 160 mA) or ± 10 V ( I
for max. 8 load cells each with 650 Ω
for max. 4 load cells each with 350 Ω
for max. 14 load cells each with 1080 Ω
+10% / -15%
= 267 mA), jumper selectable
max
48-62 Hz
