PR 5710 Additional Information

Options

2.2

2.2.1 Plug-in cards and modules (optional)

On board 1 the PR 5710 can accommodate up to 3 cards .
The PR 1713/08 card (BCD output) is not supported by the PR 5710.
Product
PR 1713/04
1 serial interface RS 232 and
1 serial interface RS 485/ RS 422.
PR 1713/06 1 analog output,
galvanically isolated
(only 1 card /06 or /07)
PR 1713/07 1 analog output and
4 analog inputs
(only 1 card /06 or /07)
PR 1713/12
4 optocoupler inputs and
4 optocoupler outputs
PR 1713/13 DIOS master, digital I/O
system for connection of PR 1720 as
nd
2 weighing point and as bus
interface for max. 256 additional dig.
I/O, (only 1 card)
PR 1713/15
4 optocoupler inputs and
4 relay outputs
PR 1713/17
6 optocoupler inputs and
8 optocoupler outputs
PR 5710/12
6 optocoupler inputs and
12 optocoupler outputs
The following options can be inserted on board 2:
Product
PR 1713/05 RAM extension
PR 1713/24 Ethernet
PR 1721 Fieldbus interface connecting unit,
max. transmission rate 12 Mbit/sec
8
The RS 485 serial interface must be configured before installation via
DIL switches on the interface card! Protocols configurable by software
set-up.
Configuration and adjustment of output levels by software. Signal
output analog 16 bits, 20,000 divisions, 0/4 - 20 mA, 0/2...10 V with
external resistor.
Output: see PR 1713/06. Input: 4 channels with common ground,
resolution 3,000 divisions.
Digital interfaces, galvanically isolated via optocouplers. Inputs and
outputs are passive. Configurable by software set-up.
Master function based on Interbus-S standard for control of digital
I/O. A PR 1720 can be used as a 2
Automatic detection of the connected modules. The max. possible
number of ports is limited to 256 bits or 4 modules. The card has
integrated termination resistors.
Similar to PR 1713/12, but configurable relay output.
Digital interfaces galvanically isolated via optocouplers. Inputs and
outputs are passive. The input group has got 1 common minus
potential, separated from 1 common minus potential for the outputs.
Similar to PR 1713/12, but higher no. of I/Os
Firmware rel. 2.20.5 or higher required.
The memory extension is detected after installation
and cold start.
Card for 10Mbit/sec network (e.g. with PR 1740)
• PR 1721/21 Profibus-DP (slave)
• PR 1721/22 Interbus-S (slave)
• PR 1721/24 DeviceNet (slave)
X6 System Weighing Controller
Function
nd
weighing point at the DIOS card.
Function
