X6 System Weighing Controller

Description of controls

2.4

2.4.1 Indicator and dialogue keys

The symbols of the front-panel keys are given below:
Indicator
keys
Gross weight is displayed while this
button is pressed (
German for Gross
Tare weight is displayed while this
button is pressed.
Set
instantaneous gross weight is stored
in the tare memory under the
following conditions:
-
-
Dialogue
keys
Exit from menu, continue operation
at next higher level
Softkey: Select an option
Scroll up the menu options
Scroll down the menu options
Move the cursor to the left during
editing
Move the cursor to the right during
editing
Function
keys
Programmable function key
Sartorius
Description
B – Brutto,
).
and reset tare.
weight is standstill
indicator is not in error status
Description
Description
PR 5710 Additional Information
Indicator
keys
The
Dialogue
keys
Function
keys
Description
Print-out
Toggle key for switching
between logical weighing
point A, B and C=A+B
Set gross weight to zero
given that:
- weight is standstill
- within zero set range
- not tared
- batching is not active
Description
Stops all batch processes
Enter / execute
Enter / execute
Back space / delete
Display the other
options. the double arrow
means, that further functions
are available
Description
Programmable function key
menu
11
