● Put the high-pressure hose so that it cannot be driven
over, stepped on, or tripped over.
● The product must only be connect to a power outlet that
is correctly earthed. Speak to an authorized electrician if
you are not sure.
● Make sure that the mains voltage corresponds to the
rated voltage on the type plate of the product. Speak to
an authorized electrician if you are not sure.
● Make sure that the product is connected to the mains
supply with a residual current device with a maximum
tripping current of 30 mA. Speak to an authorized
electrician if you are not sure.
● Do not modify the power plug. Speak to an authorized
electrician if the power plug does not fit in the power
outlet.
● Electrical connections must only be carried out by an
authorized electrician. Electrical connections must
comply with IEC60364-1.
● Do not use the power cord to carry the product.
● Do not use the power cord to pull the power plug from
the power outlet.
● Only use extension cords approved for outdoor use.
● Do not put any electrical connections directly on the
ground or floor. Electrical connections must be kept dry
and at least 60 mm above the ground or floor.
● Always pull out the complete extension cord.
● Disconnect the product from the power outlet when it is
not in operation.
● Clean the product regularly.
3

Assembly

3.1

To assemble the product

Warning! If you do not obey these instructions, there
is a risk of death or injury.
1
Install the spray wand holder with the 2 screws.
(Figure 2)
2
Attach the quick-connect end of the high-pressure
hose to the spray gun. (Figure 3)
Note! Push the release button on the spray gun to release
the high-pressure hose from the spray gun.
3
Attach the other end of the high-pressure hose to the
water outlet on the product. (Figure 4)
4

Operation

Caution! The product must be used on a secure and
stable surface in a standing, upright position. (Figure 5)
Caution! Do not let the product dry run for more than
2 minutes to avoid damage on the high-pressure pump. If
the product does not build up pressure within 2 minutes,
stop the operation of the product. Refer to "11 Troubleshoot-
ing" on page 38.
Caution! Keep a distance of at least 30 cm when the
product is used on painted surfaces to avoid damage on the
surfaces.
4.1 To attach the spray wand to the
product
(Figure 6)
1
Attach the spray wand into the spray gun.
2
Rotate the spray wand until it is completely locked
into the spray gun.
3
Attach the nozzle to the spray wand.
4.2 To connect the product to a water
source
4.2.1 To connect the garden hose to the water
inlet of the product
1
Connect the garden hose to the water inlet of the
product. (Figure 7)
2
Connect the garden hose to the garden hose adapter.
4.2.2 To use water from a tap
Caution! Unwanted materials in the water can cause
damage to the high-pressure pump and the accessories.
Make sure that the water is clean.
1
Put the product in an upright position on a level and
stable surface. (Figure 5)
2
Connect the water hose to the water inlet on the
product.
3
Connect the water hose to the tap. Make sure that the
hose is fully connected.
