Storage

Warning! Be aware of the weight of the product. Be
careful when you move the product.
Warning! Keep the product in a dry and closed
storage, away from children, when the product is not in
operation.
Warning! Do not expose the product to frost. Frost
can cause damage to the product. Always keep the product
in a frost-free environment.
1
Stop the product. Refer to "4.8 To stop the product"
on page 34
Warning! Hot water can flow out when you discon-
nect the water hose after operation.
2
Disconnect the water hose from the water inlet on the
product.
3
Disconnect the nozzle from the spray wand.
4
Turn the power switch to the "ON/1" position.
5
Hold the spray gun firmly with both hands and push
the trigger to release the pressure in the system. Push
and hold the trigger of the spray gun until no water
comes out.
6
Release the trigger of the spray gun.
7
Lock the trigger of the spray gun.
8
Turn the power switch to the "OFF/0" position.
9
Disconnect the spray wand from the spray gun and
put the spray wand and the spray gun in the spray
gun holder.
Warning! Hot water can flow out when you discon-
nect the high pressure hose after operation.
10
Disconnect the connector between the high pressure
hose and the spray gun and pull out the high
pressure hose.
11
Roll up the high-pressure hose on the hose holder.
12
Put the product on a stable and level surface in a
dust-free and frost-free storage.
36
8

Disposal

8.1 To discard the product
● Make sure that you follow local regulations when you
discard the product. Do not burn the product.
9

Technical data

Specification
Voltage
Power output
Frequency
Safety class
Protection rating
Rated pressure
Allowable pressure
Rated flow
Maximum flow
Maximum inlet pressure:
Dimensions
Weight
Sound pressure level (LpA)
Sound power level, guaranteed
(LwA)
Maximum vibrations level1
Warning! Always wear hearing protection!
Warning! The actual vibration and noise level when
using tools may differ from the specified maximum value,
depending on how the tool is used and the material. It is
therefore necessary to determine which safety precautions
are required to protect the user, based on an estimate of
exposure in actual operating conditions (taking into account
all stages of the work cycle, e.g. the time when the tool is
switched off and when it is idling, in addition to the start-up
time).
1 The declared values for vibration and noise,
which have been measured according to a
standardized test method, can be used to
compare different tools with each other and
for a preliminary assessment of exposure. The
measurement values have been determined in
accordance with EN 60335-2-79:2012.
Value
220–240 V ~
1600 W
50/60 Hz
II
IPX5
7.5 MPa
11 MPa
5.1 l/min
7 l/min
1.0 MPa
260x262x708 mm
5.52 kg
75.2 dB(A), K= 3 dB
92 dB(A), K= 3 dB
)
6.2 m/s², K=1.5 m/s²
