TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
IP classification:
Protection class:
Power connection:
Power output:
Fuse:
Lamp type:
LED:
Color temperature:
Equipment:
DMX channels:
DMX input:
DMX output:
Cooling:
Control:
Beam angle (1/2 peak):
Beam angle (1/10 peak):
Color rendering index (CRI):
Housing color:
Attachment system:
Display type:
Dimensions:
Weight:
100-240 V AC, 50/60 Hz
280 W
IP20
Protection class I
Mains input via P-Con (blue), mounting version
Power supply cord with safety plug
P-Con (gray), mounting version
5 x 20 mm, T 3,15 A Fuse replaceable
LED lamp
1 x 350 W COB (chip-on-board) 2in1 BCL CW/WW
(homogenous color mix)
2700K - 6500K adjustable
Zoom motor-driven
4; 5
3-pin XLR (M) mounting version
5-pin XLR (M) mounting version
3-pin XLR (F) mounting version
5-pin XLR (F) mounting version
Temperature-controlled fan
Stand-alone; Master/slave function; DMX
11 - 27°
22 - 41°
95 Ra
Black
Mounting bracket
LCD display
Length: 43,5 cm
Width: 28,5 cm
Height: 38,5 cm
10,5 kg
285 mm
27/28
435 mm
00147009.DOCX, Version 1.0
