INSTALLATION
WARNING! Risk of injury caused by falling objects
Devices in overhead installations may cause severe injuries when crashing down. Make sure that the
device is installed securely and cannot fall down. The installation must be carried out by a specialist who
is familiar with the hazards and the relevant regulations.
The device may be placed via the mounting bracket on a lighting stand or fastened to a truss or similar rigging
structure. The device must never be fixed swinging freely in the room.
1
The rigging structure must support at least 10 times the weight of all fixtures to be installed on it.
2
Block access below the work area and work from a stable platform
when installing the device.
3
Use rigging hardware that is compatible with the structure and capable
of bearing the weight of the device. Please refer to the Accessories
section for a list of suitable rigging hardware.
4
Secure the device with a safety bond or other secondary attachment.
This secondary safety attachment must be sufficiently dimensioned in
accordance with the latest industrial safety regulations and constructed
in a way that no part of the installation can fall down if the main
attachment fails. An appropriate eyelet is mounted on the device for
fixation of the safety bond. Fasten the safety bond in such a way that,
in the event of a fall, the maximum drop distance of the device will not
exceed 20 cm
5
To align the device, release the fixation levers at the mounting bracket,
adjust the desired inclination angle and tighten the fixation levers.
6
After installation, the device requires inspections periodically to prevent
the possibility of corrosion, deformation and looseness.
Installation on a lighting stand
Please note: All devices, lighting effects and crossbeams attached on a stand must be secured with a secondary
attachment!
1
Attach an appropriate adapter or TV-adapter to the top end of the stand and fasten it with the fixation screw.
2
Attach the mounting bracket of the theater spot onto the TV-adapter and tighten the fixation screw.
3
The given carrying capacity of the stand must not be exceeded. Please consult the appropriate user manual
for further information.
4
To align the device, release the fixation levers at the mounting bracket, adjust the desired inclination angle and
tighten the fixation levers.
5
After installation, the device requires inspections periodically to prevent the possibility of corrosion,
deformation and looseness.
20/28
00147009.DOCX, Version 1.0
