Menu structure
Main Menu
DMX Adr
001
DMX Loss
Off
Channel
4
Master
Off
Perform
P-000
Man Dim
Fan
Auto
Display
Info
Stand-alone mode
In stand-alone mode, the device can be used without controller. Disconnect the device from the controller and call
up the menu you want to use. Please refer to the instructions under Menu structure.
Sub menu
Function
DMX Adr
Setting the DMX starting address
001 - 511
Device switches off automatically when separated
DMX Off
from DMX signal
Device runs the last set program in Stand Alone
DMX Hold
Mode when separated from DMX signal
Setting DMX Mode
4CH
4-Channel DMX Mode
5CH
5-Channel DMX Mode
MASTER: OFF
Slave Mode on
MASTER: ON
Master Mode on
000 – 004
Auto Programs (Master-Mode)
000
No function
001
WW
002
CW
003
WW und CW
004
Color temperature changes automatically
Manual Dimmer (Master-Mode)
MAN DIM
0-255 with increasing brightness
C--WHITE
MAN DIM
0-255 with increasing brightness
W--WHITE
FAN
Fan runs automatically
AUTO
FAN
Fan on
ON
Display shutoff time
BACK LIT
Display shuts off after 5 seconds
AUTO-5
BACK LIT
Display shuts off after 10 seconds
AUTO-10
BACK LIT
Display shuts off after 30 seconds
AUTO-30
BACK LIT
Display shuts off after 60 seconds
AUTO-60
BACK LIT
Display on
ON
BACK LIT
Set display brightness
0-255
LED TEMP
LED-Temperature
###
HOURS
#####
SERIAL
########
SFTVER
Software version
VER ##
Running time
Serial number
23/28
Read out only
00147009.DOCX, Version 1.0
