Instructions for sharpening a saw chain:
Upper tilt angle
File diameter Upper angle lower angle Standard depth
(55 °)
Chucking rotation Chucking
Chainsaw type
side angle
angle inclination angle
21PBX approx. 4,8 mm 30° 10° 85° 0,64 mm
depth stop file
Important hint in case of sending the equipment
to a service station:
Due to security reasons please see to it that the
equipment is sent back free of oil and gas!
Instructions for periodic maintenance
To ensure long life, prevent damage and ensure the
full functioning of the safety features the following
maintenance must be performed regularly. Guaran-
tee claims can be recognized only if this work is per-
formed regularly and properly. Failure to perform the
prescribed maintenance work can lead to accidents!
The user of the chain saw must not perform mainte-
nance work which is not described in the instruction
manual.
All other work may only be performed by a special-
ist workshop.
