Using the keypad
Key
<Mode>
<+>
<->
<Write/Set>
<Read/On>
4.
Connections
Connection
Addressing
connector
Program
loading
connector
Note:
The designations of the different keys are indicated with the key name in
pointed brackets and bold print.
Example:
The displays and the different functions are indicated in inverted
commas and bold print.
Example:
Selection of the addressing or program loading / storage function
Changeover between the different modes
Increment slave address/extended ID code 1
Decrement slave address/extended ID code 1
Write slave address/extended ID code 1 / confirm mode
Read out slave address/extended ID code 1 / switch on the device. To
do so, press the key for approx. 0.5 s.
5-pole M12 connection socket for the addressing cable
e.g. addressing cable for the mechanical addressing interface E70213
addressing adapter for compact modules E70123
IR addressing adapter E70211
9-pole SUB-D plug for the connection to the controller or PC
with a null modem cable (e.g. AC4010) or to SmartLogic with the
addressing cable E70239
Jack socket for the connection of an external supply voltage
(upper front face)
Location for the storage card (upper front face)
<Mode>
identifies the mode key
"Function ASi Adr"
Function
Description
