Charging:
Connect the USB plug of the charging cable to a USB port of a computer/laptop or a USB charger.
Connect the reverse polarity-protected micro connector of the charging cable to the connection plug of the flight
battery.
Charging starts automatically, and the charging control LED on the USB plug goes on.
When charging is complete and the flight battery is fully charged, the red LED of the USB plug goes out.
Disconnect the charging cable from the flight battery immediately after charging and unplug the USB charging
cable from the computer/laptop or USB charger.
USB charger LED status indicator
Off
On

12.2 Inserting batteries into the remote control

Always insert a whole set of new batteries into the transmitter. Do not mix full batteries with half-full ones.
Always use batteries of the same type and from the same manufacturer.
1. Use the supplied cross-head screwdriver to open the battery compartment.
2. Then, insert three AAA batteries by following the instructions for the correct polarity inside the battery compart-
ment.
3. Close the cover again.

12.3 Inserting the battery into the drone

Set the switch on the underside of the quadcop-
ter to "OFF".
Open the battery holder on the underside. Do
this by pressing in the small pin on the back and
sliding the cover away to the rear.
Explanation
Fully charged
Charging process
