Structure
Structure
The pressing tool consists of:
- Pressing tool incl. operating instructions
- Pressing jaws
- Battery charger incl. operating instructions
- Rechargeable battery 12 V DC
- Safety notes
- Addresses for service
- Transport case
The equipment may vary depending on the scope of delivery.
1
5
4
1 Pressing tool
2 Pressing jaw
3 Retaining pin
4 Roller drive
5 Rechargeable battery
Technical data
Nominal voltage
Power consumption
Nominal force
Protection degree
Net weight
Sound pressure level at user's ear
Vibration emission value
Operating temperature
Battery capacity
Measurement inaccuracy of the sound pressure level: 3 dB(A)
Measurement inaccuracy of the vibration emission value: 1.5 m/s
The stated vibration emission value has been measured according to a standardised test process and can be used for
comparison with another device. The stated vibration emission value can also be used for an introductory estimation of
the exposure.
Please note: The vibration emission value can differ from the stated value during the actual use of the device, depending
on the way the device is used. Depending on the actual operating conditions (intermittent operation), it can be necessary
to determine safety measures to protect the operator.
12
2
3
12 V DC
240 W
19 kN
IP 20
1.7 kg
76 dB(A)
≤ 2.5 m/s
-20 – +60 °C
1.5 Ah
