Simons Voss Technologies SmartBridge Gateway Node 2 Kurzanleitung Seite 3

SmartBridge Gateway Node 2
RouterNode 2
4. Connections
1
DC In
5. Installation
2
3
Abbildungen/Images
RJ45 ANT
4. Connections
GND
IO-Vout
+ 3.3 V
Analog Input
Unused
DI 3
DI 2
DI 1
IO
O 3
O 2
O 1.NC
O 1.NO
O 1.COM
