schmersal MZM 100 ST2-1P2P-A Test Bedienungsanleitung Seite 8

Designation, Safety inputs
Koplingsterskler på sikkerhetsinnganger
Driftsstrøm for sikkerhetsinngangene ved 24 V
Test pulse duration, maximum
Test pulse interval, minimum
Classification ZVEI CB24I, Sink
Classification ZVEI CB24I, Source
Electrical data - Safety digital outputs
Designation, Safety outputs
Driftssstrøm (sikkerhetsutganger)
Sikkerhetsutgang
Voltage drop U , maximum
d
Leakage current I , maximum
r
Voltage, Utilisation category DC-13
Current, Utilisation category DC-13
Test pulse interval, typical
Test pulse duration, maximum
Classification ZVEI CB24I, Source
Classification ZVEI CB24I, Sink
Elektriske data - diagnoseutgang
Designation, Diagnostic outputs
Design of control elements
Voltage drop U , maximum
d
Voltage, Utilisation category DC-13
Current, Utilisation category DC-13
Statusvisning
Merk (Lysdiode for brytertilstandsindikator)
Pin-tildeling
PIN 1
PIN 2
X1 and X2
−3 V ... 5 V (Low)
15 V ... 30 V (High)
5 mA
1 ms
100 ms
C1
C1
C2
C3
Y1 and Y2
250 mA
short-circuit proof, p-type
1 V
0,5 mA
24 VDC
0,25 A
1000 ms
1 ms
C1
C1
OUT
short-circuit proof, p-type
2 V
24 VDC
0,05 A
Koblingsforhold: gul lysdiode
Feil funksjonell defekt: rød lysdiode
Tilførselsspenning UB: grønn lysdiode
A1 Matespenning
X1 Sikkerhetsinngang 1
