schmersal MZM 100 ST2-1P2P-A Test Bedienungsanleitung Seite 6

PFH-verdi
Safety Integrity Level (SIL), suitable for applications in
Mission time
Mekaniske data
Mekanisk levetid, minimum
Note (Mechanical life)
Holding force, typically
Holding force, guaranteed
Type of the fixing screws
Tightening torque of the fixing screws
Mechanical data - Switching distances according EN IEC 60947-5-3
Sikret bryteravstand "PÅ"
Sikret bryteravstand "AV"
Mechanical data - Connection technique
Length of sensor chain, maximum
Note (length of the sensor chain)
Note (series-wiring)
Konnektor stikk
Mekaniske data - mål
Lengde på sensor
Bredde på sensor
Høyde på sensor
Omgivelsesbetingelser
Tetthetsgrad
Ambient temperature
Storage and transport temperature
Relativ fuktighet, minimum
Relativ fuktighet, maksimum
3,54 x 10⁻⁹ /h
3
20 år
1 000 000 bevegelser
Aktueringshastighet ≤ 0,5 m/s
Operasjoner for vakter ≤ 5 kg
750 N
500 N
2x M6
8 Nm
0 mm
1 mm
200 m
Cable length and cross-section change the voltage drop dependiing
on the output current
Unlimited number of devices, oberserve external line fusing, max.
31 devices in case of serial diagnostic SD
Konnektor M12, 8-polet
40 mm
40 mm
177,5 mm
IP65
IP67
-25 ... +55 °C
-25 ... +70 °C
30 %
95 %
6-26
