Press the adjusting dial
Controls and in-
dicators on the
RC Panel Stan-
dard TIG
(1)
42
- Apply highlighted elements, e.g. to change the value of a wel-
ding parameter.
- Apply values of certain welding parameter.
(3)
(2)
(1)
Left adjusting dial with turn/press function
To select, change and set parameters
Turn the adjusting dial: Change values, select parameters
Press the adjusting dial: Confirm a selection in a menu, apply values
Adjustable parameters:
(4) (5)
(13)
(6)
(12)
(7)
(8)
(9)
(10)
(11)
