KIKKA BOO i-FELIX Gebrauchsanweisung Seite 13

IMPORTANT! KEEP FOR FUTURE REFERENCE!
EN
READ CAREFULLY!
fitted.
Step 2: Pull out the top tether as shown in the figure.Use the adjustment buckle on the top tether to adjust the top tether to the appropriate length. As shown in the figure, hang the
top tether on the corresponding hook of the car (the node recommended in the carmaker's manual). Finally, the top tether is tightened, and when the top tether is fixed, the regulator
shows green.
Step 3: First loosen the pull-out buckle and shoulder strap, put the child into the child seat, and then buckle the pull-out buckle to tighten the shoulder strap. Check shoulder strap and
head height. Note: All seat belts must not be distorted. Its regulator shows green.
4.6-4.7 Installation of the child safety seat (Height: 100-150cm)
This product is suitable for children height: 100-150cm, Forward installation
Remove the harness system and buckle, hide the whole buckle in the hole on the base which is under the cover.
Step 1: Adjust the child safety seat to the most upright position.
Step 2: Insert the ISOFIX to the isofix connector on you car. Make sure that the ISOFIX display window is green. Then push the child safety seat to the backrest of your car seat until it is
fully fitted.
Step 3: Place your child into the child safety seat and fix your child with 3-point safety belt. Note: All seat belts shall not be twisted.
4.9-4.14 Removal of seat belts and buckles
Step 1: Loosen the belt system.
Step 2: Pull the belt system out of their metal brackets on the back side of the child car seat, guide these through the child car seat to the front side.
Step 3: Remove the seat cushion and remove shoulder pads.
Step 4: Separate the buckle tongues from the buckle. Turn over the seat cover, then through the shoulder belts of each side from the cover opening. Remove the crotch pad, through the
buckle from the cover opening to the back.Take the tongues from the belts then insert to the buckle.
Step 5: Fold the belt on the sides. Hide the buckle with its tongues in the hole on the base.
V. REMOVAL AND INSTALLATION OF THE FABRIC COVER
5.1-5.2
•
Remove shoulder straps and shoulder covers;
•
Release the buckle first, then remove the crotch pad and seat cushion.
•
Unbutton the headrest and base, respectively, and remove the sleeve. Note: if you need to install the cover again, please operate in reverse order of removal.
VI. MAINTENANCE AND CLEANING
ROUTINE MAINTENANCE
•
During daily use, child safety seat's wear and tear should be checked regularly. In the event of an accident, the seat needs to be replaced.
•
When not using child safety seats, place them in a dry, ventilated place to avoid damp and mildew.
•
If dust is found on the surface of the child safety seat, dry the seat belt and plastic parts with a damp sponge and then dry by ventilation.
•
If you drop food or drink onto your seat belt, remove it and rinse it with warm water, then dry by ventilation.
Produced for Kikka Group Ltd., Vasil Levski 121, Plovdiv, Bulgaria. Made in China.
Complies with EN R129.
ENGLISH
