• Do not cover the device, even partially e.g. with metallic plates
or film. This may result in overheating.
• Protect the device and accessories from bumps and impacts.
• Keep the base plate clean.
• Observe the minimum distances:
- between devices min. 100 mm,
- between device and wall min. 100 mm,
- above the device min. 800 mm.
Intended use
/// Use
• The magnetic stirrer is suitable for mixing and / or heating substances.
/// Area of use
• Indoor environments similar to that a laboratory of research, teaching, trade or industry area.
• The safety of the user cannot be guaranteed:
- if the device is operated with accessories that are not supplied or recommended by the manufacturer,
- if the device is operated improperly or contrary to the manufacture's specifications,
- if the device or the printed circuit board are modified by third parties.
Unpacking
/// Unpacking
• Please unpack the device carefully
• In the case of any damage a detailed report must be sent immediately (post, rail or forwarder)
/// Scope of delivery
• Heating magnetic stirrer / Magnetic stirrer / Heating device
• Mains cable
• Operating instructions
14
> 100 mm > 100 mm
Commissioning
MS 4 MS 7 MS 10 HS 4
Put device switch (A) in the OFF position.
Plug in mains cable (G).
Commissioning
Once connected to the power supply the device is in "stand-by" mode.
The right decimal point on the display (C) is lit.
Put device switch (A) in the ON position.
Any set values are retained when device is switched off and even after
Stirring
the device is disconnected from the power!
Set the engine speed with the operating button (E) on the right.
Put device switch (A) in the ON position.
Any set values are retained when device is switched off and even after
the device is disconnected from the power!
Set the target temperature for the heating plate using operating button
(D) [for VHP (E)].
Heating
The set value is indicated on the display (C). If energy is being supplied
to the heating plate, the red LED (B) lights up.
In the stir and stand-by modes,
heat has been switched off for as long as the temperature of the set-up
surface exceeds 50 °C.
Contact thermome-
ter connection
HS 7 HS 10 HP 4 HP 7 HP 10
flashes on the display after the
Put device switch (A) in the OFF position, unplug contact
plug.
Safety contact thermometer connected with jack (H).
Put device switch (A) in the ON position.
Beware the instruction manual of the contact thermometer.
Notice: Display (C) also indicates the target temperature of
the heating plate when the contact thermometer is connec-
ted.
