Input Command: ENDS [CR]
Return Value: [OK] [CR]
Input Command: GDLT location {0-5} [CR]
Return Value: delta time [00-20] [CR] [OK] [CR]
Input Command: SDLT location {0-5} time {00-20}
[CR]
Return Value: [OK] [CR]
Input Command: GSWT location {0-2} [CR]
Return Value: SW time [000-600] [CR] [OK] [CR]
Input Command: SSWT location {0-2} time {000-
600} [CR]
Return Value: [OK] [CR]
Input Command: RUNP first {0-2} end {0-2}[CR]
Return Value: [OK] [CR]
Input Command: STOP [CR]
Return Value: [OK] [CR]
Input Command: SETM
<Setv[1] >
<Seti[1] >
<Swtime[1]>
<Setv[2] >
<Seti[2] >
<Swtime[2]>
<Setv[3] >
<Seti[3] >
<Swtime[3]> [CR]
Return Value: [OK] [CR]
Input Command: GALL[CR]
Return Value:
<AbcSele>
<Get Channel>
<Get UVL>
<Get UCL>
<Get Output >
<Swtime[1]>
<Swtime[2] >
<Swtime[3] >
<Deltatime[1-6]>
<mode>
<Setv[1]>
<Seti[1] >
<Setv[2] >
<Seti[2] >
<Setv[3]>
<Seti[3] >
<Setv[4] >
<Seti[4]> [CR] [OK] [CR]
Enable Keyboard
Get delta time setting value
DeltaTime[1] : Time of Preset1 to Preset2
DeltaTime[2] : Time of Preset2 to Preset1
DeltaTime[3] : Time of Preset1 to Preset3
DeltaTime[4] : Time of Preset3 to Preset1
DeltaTime[5] : Time of Preset2 to Preset3
DeltaTime[6] : Time of Preset3 to Preset2
*Set- DeltaTime <=20S
Set delta time
*Set- DeltaTime <=20S
Get SW time
SwTime[1]: Time of Preset1
SwTime[2]: Time of Preset2
SwTime[3]: Time of Preset3
*Set- SwTime <=600S
Set SW time
*Set- SwTime <=600S
Run SW running
Stop SW running
Set to Memory of preset1/2/3
<Setv[1] >=????
<Seti[1] > =????
<Swtime[1]>=???
<Setv[2] > =????
<Seti[2] > =????
<Swtime[2]>=???
<Setv[3] >=????
<Seti[3] > =????
<Swtime[3]>=???
Get information from Power Supply
<AbcSele> =?
<Get Channel> =？
<Get UVL> =????
<Get UCL> =????
<Get Output > =?
<Swtime[1]> =???
<Swtime[2] > =???
<Swtime[3] > =???
<Deltatime[1-6]> =????????????
<mode> =????
<Setv[1]> =????
<Seti[1] > =????
<Setv[2] > = ????
<Seti[2] > =????
<Setv[3]> =????
<Seti[3] > =????
<Setv[4] > =????
<Seti[4]> = ????
* Setv[4] Normal Mode Voltage
Seti[4] Normal Mode Current
P.25
Input Command: ENDS [CR]
Return Value: [OK] [CR]
Meaning: Enable Keyboard
Input Command: GDLT 0CR]
Return Value: 10 [CR] [OK] [CR]
Meaning: DeltaTime[1] is 10S
Input Command: SDLT 205[CR]
Return Value: 1 [CR] [OK] [CR]
Meaning: DeltaTime[3] is set to 20S
Input Command: GSWT [CR]
Return Value: 0100 [CR] [OK] [CR]
Meaning: SwTime[1] is 100S
Input Command: SSWT0100[CR]
Return Value: [OK] [CR]
Meaning: SwTime[0] is set to 100S
Input Command: RUNP 01[CR]
Return Value: [OK] [CR]
Meaning: start running SW run A_B
Input Command: STOP [CR]
Return Value: [OK] [CR]
Meaning: Stop SW running
Input Command: SETM
05001000010
13801000015
40000400020
[CR]
Return Value: [OK] [CR]
Meaning:
preset1voltage is set to 5.00V
Current10.00A SwTime 10S
preset1voltage is set to 13.80V
Current10.0A SwTime 15S
preset1voltage is set to 40.00V
Current10.0A SwTime 20S
Input Command: GALL[CR]
Return Value:
3
0
4220
1020
1
350
001
001
00 00 00 00 00 00
8160
1000
0100
2000
0200
3000
0300
4000
0400 [CR]
[OK] [CR]
Meaning:
<AbcSele> =3 Normal Mode
<Get Channel> =0 un ues
<Get UVL> =4220
<Get UCL> =1020
<Get Output > =1
<Swtime[1]> = 350
<Swtime[2] > = 001
<Swtime[3] > =001
<Deltatime[1]> =00
