12.5 Befehlssatz für eigene Programmierung
12. Command Set
Command set of SSP-8160 V0.0.1
Command code & return value
Input Command: SOUT< Output > [CR]
Return Value: [OK] [CR]
Input Command: GOUT [CR]
Return Value:<Output> [CR] [OK] [CR]
Input Command: GOVP [CR]
Return Value: <Voltage>[CR] [OK] [CR]
Input Command: GOCP [CR]
Return Value:<Current>[CR] [OK] [CR]
Input Command: SETD <preset0/1/2/3>
<VOLTAGE> <CURRENT> [CR]
Return Value: [OK] [CR]
Input Command: SOVP <voltage > [CR]
[Return Value:[OK] [CR]
Input Command: SOCP <Current> [CR]
Return Value: [OK] [CR]
Input Command: GETD [CR]
Return Value: <Voltage ><Current> <CV/CC Mode>
[CR] [OK] [CR]
Input Command: GETS< preset0/1/2/3>[CR]
Return Value: <Voltage><Current>[CR] [OK] [CR]
Input Command: VOLT < preset0/1/2/3>
<Voltage>[CR]
Return Value: [OK] [CR]
Input Command: CURR < preset0/1/2/3> <Current>
[CR]
Return Value: [OK] [CR]
Input Command: GABC [CR]
Return Value: < preset0/1/2/3> [CR] [OK] [CR]
Input Command: SABC < preset0/1/2/3> [CR]
Return Value: [OK] [CR]
Input Command: SESS [CR]
Return Value: [OK] [CR]
24
Description
Set Output on/off
Set Output off: < Output > =0
Set Output on: < Output > =1
Get Output Status
Output off: < Output > = 0
Output on: < Output > = 1
Get upper limit of output Voltage
<voltage>=????
Get upper limit of output Current
< Current >=????
SET preset0/1/2/3 Voltage and Current
<preset0/1/2/3> =0 preset1
<preset0/1/2/3> =1 preset2
<preset0/1/2/3> =2 preset3
<preset0/1/2/3> =3 Normal Mode
<voltage> = ????
< Current > = ????
Set Over Voltage value
<voltage> = ????
Set Over current value
< Current > = ????
Get Reading Volt & Curr mode
<voltage>
=
????
< Current >
=
????
<CV Mode> =0 CV Mode
<CV Mode> =1 CC Mode
Get Setting preset0/1/2/3 Volt & Curr
SET preset0/1/2/3 Voltage and Current
<preset0/1/2/3> =0 preset1
<preset0/1/2/3> =1 preset2
<preset0/1/2/3> =2 preset3
<preset0/1/2/3> =3 Normal Mode
<voltage> = ????
< Current >=????
Set output Voltage
*Set-Volt value relevance to preset Current
value total power<160W .Max-Volt value
refer to product specification
SET output Current
* Set-Cur value relevance to preset Volt value
total power<160W .Max- Current value refer
to product specification
Get preset selection
< preset0/1/2/3> =0 preset1
< preset0/1/2/3> =1 preset2
< preset0/1/2/3> =2 preset3
< preset0/1/2/3> =3 Normal Mode
Set ABC select
< preset0/1/2/3>=0 preset1
< preset0/1/2/3>=1 preset2
< preset0/1/2/3>=2 preset3
< preset0/1/2/3>=3 Normal Mode
Disable Keyboard
P.24
Example
Input Command: SOUT0[CR]
Return Value: [OK] [CR]
Meaning: Set Output off
Input Command: GOUT [CR]
Return Value: 0 [CR] [OK] [CR]
Meaning: Output is off
Input Command: GOVP [CR]
Return Value: 4220 [CR] [OK]
[CR]
Meaning: upper limit of output
Voltage is 42.40V
Input Command: GOCP [CR]
Return Value: 1020 [CR] [OK]
[CR]
Meaning: upper limit of output
Current is 10.20A
Input Command: SETD 005001000
[CR]
Return Value: [OK] [CR]
Meaning: Set preset1 voltage
5.00V Current 10.00A
Input Command: SOVP4200[CR]
Return Value: [OK] [CR]
Meaning: Set upper limit of output
Voltage 42.00V
Input Command: SOCP1000[CR]
Return Value: [OK] [CR]
Meaning: Set upper limit of output
Current 10.00A
Input Command: GETD [CR]
Return Value: 050001000[CR] [OK]
[CR]
Meaning: The Display value is
5.00V and 1.00A.
It is in CV mode.
Input Command: GETS0[CR]
Return Value: 05000100[CR] [OK]
[CR]
Meaning: The Memory preset 1
voltage value is 5.00V and Current is
1.00A.
Input Command: VOLT 01000[CR]
Return Value: [OK] [CR]
Meaning: Set Memory preset 1
voltage value is 10.00V
Input Command: CURR 00100[CR]
Return Value: [OK] [CR]
Meaning: Set preset 1 Current value
is 1.00A
Input Command: GABC [CR]
Return Value: 0 [CR] [OK] [CR]
Meaning: Preset Mode is Preset1
Input Command: SABC 2[CR]
Return Value: [OK] [CR]
Meaning: Preset Mode is set to
Preset3
Input Command: SESS [CR]
Return Value: [OK] [CR]
Meaning: Disable Keyboard
